Screw Fastening Machine and Stability Omron Photoelectric Switch 500*500*100mm 50/60Hz
Price:
Negotiable
MOQ:
1 set
Delivery Time:
7~9 work days
Brand:
HSTECH
Product Description
Screw Fastening Machine and Stability Omron Photoelectric Switch 500*500*100mm 50/60Hz
Introduction
The screw machine consists of feeding and locking system, the feeding part (screw arranger/feeder) simplifies the arrangement and enhances the efficiency, it is a widely used automation equipment for the electronics industry, suitable for M1-M6 screws.
Specification
| Model | HS-SL551S | HS-SL661S |
| Production name | Automatic Screw Locking Machine | |
| Moving range(X/Y/Z) | 500*500*100mm | 600*600*100mm |
| X/Y axis moving speed | Closed loop motor :1-800mm/s | |
| Z axis moving speed | Closed loop motor: 1-300mm/s | |
| X/Y axis max load | Closed loop motor: 5KG | |
| Z axis max load | Closed loop motor: 3KG | |
| Power supply | AC110V/220V, 50/60Hz | |
| Repeat accuracy | ±0.02mm | |
| Document support | CAD CorelDraw | |
| Suitable screws | M1-M5 | |
| Machine dimension | 746*785*800mm | 845*885*800mm |
| Machine weight | 50kg | 55kg |
Main parts brand
1, Motor: Shinano
2, Guide: Hiwin
3, Photoelectric switch: Omron
4, Power supply: Meanwell
Features
1.Efficient inhalation feeding to enhance work efficiency.
2.Desktop visual operation, compatible with automatic production line.
3.Move range optional: 500x500x100mm or 600x600x100mm.
4.Support multi-screw bin suction mode.
5. Wide range of extended applications, including dispensing, welding, testing, etc.
6. Suitable for multi-axis and dual-platform operation.
7. With a variety of editing and copying functions.
8. Operating parameters can be downloaded offline, supporting handheld box storage and recall.
9. Strong machine storage capacity, support hundreds of processing files, up to 1000 screw bits per file.
2.Desktop visual operation, compatible with automatic production line.
3.Move range optional: 500x500x100mm or 600x600x100mm.
4.Support multi-screw bin suction mode.
5. Wide range of extended applications, including dispensing, welding, testing, etc.
6. Suitable for multi-axis and dual-platform operation.
7. With a variety of editing and copying functions.
8. Operating parameters can be downloaded offline, supporting handheld box storage and recall.
9. Strong machine storage capacity, support hundreds of processing files, up to 1000 screw bits per file.
