0~20000psi Type D Type F Oil Field Drilling Mud Pump Pressure Gauge

Type: Model D & F Pressure Gauge

Mud pump pressure gauge is mainly used for measuring fluctuating pressure, transient pressure and static pressure in the petroleum, coal, chemical industry, drilling, and mechanism. The gauge is also used for the measurement of stationary pressure.

Specifications

Type D:

• Dimensions: 7-5/8 inch diameter dial case and 14-3/4 inch in height
• Pressure range: 0-6,000 psi(1000 psi, 3000 psi, 5000 psi, 6000 psi)
• Standard end connection: 2 inch NPT female threaded connection
• Interchangeable with: Cameron type 'D'

Type F:

• Dimensions: 4-7/8 inch diameter dial case and 9-7/8 inch in height.
• Pressure range: 0-20,000 psi
• Standard end connection: 2" NPT threaded female and 1" NPT threaded male connection.
• Interchangeable with: Cameron type 'F'

Features

1) Suitable for compression crack, solid mergence and spray resistant equipment
2) Can also be used to measure static pressure
3) Sound shock resistant performance
4) The pulse of the damp mechanism inside the apparatus within the pressure range doesn't need to be regulated in use
5) It not only can measure the violently fluctuated pressure, but also bear the instantaneous pressure impact and the frequent shaking in the
mounted position and during the transport process
6) Smooth and clear indication
7) Measured media has no access to inner "anti-block"
21,000kPa, 35,000kPa, 40,000kPa,
21MPa, 35MPa, 40MPa,
210bar, 350bar, 400bar
