High Speed Automatic Non woven Bouffant Cap Making Machine
|
High Speed Automatic Bouffant Cap Making Machine |
|
|
|
|
|
This Bouffant Cap Making Machine is specially designed to produce disposable nonwoven or PE bouffant caps (mob cap) automatically with extremely high speed. from raw material from feeding to finished caps counting. It could produce 18" , 21" , and 24" caps. Cap size changeable without changing moulds. One worker can operate 2 machines at the same time.
|
 |
1) High production, one machine can make different sizes.
2) Non woven material or PE material can work on one machine.
3) Speed controlled by frequency converter, and automatic constant temperature control.
4) Ultrasonic welding combined with electric heating to make the product more comfortable and firm.
5) The main components are made of aluminum to make the machine lighter and smoother.
| Model | HD-R1005 |
| Speed (non woven) | 180-210 pcs/min |
| Speed (PE) | 110-130 pcs/min |
| Voltage | 220V |
| Power | 5kw |
| Net weight | 850kg |
| Machine dimension | 3900*820*1550mm (L*W*H) |
| Cap size |
18" , 21" , and 24" |
Automatic feeding -import- folding - welding - forming and cutting to output
|
|
