AG018-A Waterproof IP66 Single Arm LED Garden Light for Parks, Gardens & Urban Pathways.
AG018-A Waterproof IP66 Single Arm LED Garden Light for Parks, Gardens & Urban Pathways.
Description:
The AG018-A LED garden light is a high-power outdoor lighting solution designed for parks, pathways, residential communities, public squares, and landscape projects. Featuring a modern single-arm structure, high-efficiency LED modules, and durable die-casting aluminum housing, it provides reliable illumination with excellent outdoor durability.
Available in 100W, 120W, and 150W configurations, the AG018-A is ideal for projects requiring both decorative outdoor aesthetics and high-performance functional lighting.
With professional optical distribution, smart dimming compatibility, and optional surge protection, this fixture is suitable for municipal, commercial, and residential lighting applications.
Specifications:
| Model No | MOON-STAR AG018-A | ||
| Power | 100W | 120W | 150W |
| Len chips Qty (3030) | 108 | 144 | 144 |
| Len chips Qty (5050) | 36 | 48 | 48 |
| Luminaire Flux (LM) | 12500 | 15000 | 18000 |
| LED Chips | Led (other brand of led upon request) | ||
| Luminaire Efficacy | 130-150 LM/W | ||
| CCT | 4000K (2700-6500K upon request) | ||
| CRI | 70 (80 upon request) | ||
| Lifetime | 108000H (at 25℃ ambient temperature) | ||
| Operating Temperature | -30℃→55℃ | ||
| Driver | Meanwell/Inventronics (other brand of driver upon request) | ||
| Electrical | Class I or Class II Input voltage: 100-277VAC/50-60HZ; 108-305VAC/50-60HZ 10KV/20KV SPD Cut-off connector (Power automatically switch off when opening) |
||
| Beam angle | TYPE II, TYPE III | ||
| Dimming | DALI / 1-10V / PWM / FIVE LEVELS DIMMING / | ||
| Options | Photocell / Surge protection device / External cable (different length upon request) | ||
| Color | Grey / Black / White (other color upon request) | ||
| Tightless Level | IP66 | ||
| Impact Resistance | IK08 | ||
| Standards & Certification | ISO 9001:2015 CE / RoHS |
||
Why Choose AG018-A Outdoor Garden Light?
1. Modern Single-Arm Design for Urban Landscapes
The streamlined single-arm structure delivers a modern architectural appearance, making it suitable for parks, residential roads, pathways, and commercial outdoor environments.
2. High Brightness for Large Outdoor Spaces
With luminous efficacy up to 150lm/W and lumen output up to 18,000lm, the AG018-A provides efficient illumination for larger public areas while reducing energy consumption.
3. Professional Outdoor Reliability
Designed with IP65 waterproof protection and IK08 impact resistance, the fixture performs reliably in rain, dust, humidity, and changing outdoor temperatures.
4. Smart Lighting Control Compatibility
Supports multiple intelligent control systems including:
- DALI dimming
- 1-10V dimming
- PWM dimming
- Five-level dimming
Helping reduce energy consumption and supporting smart city lighting management.
5. Flexible Beam Distribution
TYPE II and TYPE III beam angles provide optimized lighting for:
- Pathways
- Parks
- Courtyards
- Residential roads
- Public plazas
Ensuring uniform illumination and visual comfort.
6. Premium Components for Long Lifespan
Equipped with high-quality LED chips and Meanwell / Inventronics drivers, the fixture delivers stable performance and operational lifespan up to 108,000 hours.
7. Suitable for Decorative & Functional Projects
The AG018-A combines decorative outdoor design with practical high-power illumination, making it ideal for municipal and commercial landscape projects.
How to Choose the Right LED Garden Light?
1. Select Power According to Area Size
| Application | Recommended Power |
|---|---|
| Garden pathways | 60W–100W |
| Parks & plazas | 100W–120W |
| Public squares & large areas | 150W |
2. Consider Lighting Distribution
Professional optical systems improve lighting coverage and reduce dark areas.
3. Importance of Smart Dimming
Intelligent dimming systems help reduce operational costs and improve lighting management efficiency.
4. Outdoor Protection Requirements
IP65 waterproof and IK08 impact resistance are recommended for long-term outdoor projects.
FAQ:
Q1: Is AG018-A suitable for public parks?
Yes, it is designed for parks, pathways, and landscape projects.
Q2: Does the fixture support smart dimming?
Yes, it supports DALI, 1-10V, PWM, and multi-level dimming systems.
Q3: Can it be used in rainy environments?
Yes, IP65 waterproof protection ensures reliable outdoor performance.
Conclusion:
The AG018-A LED garden light combines modern single-arm aesthetics, intelligent lighting control, high luminous efficiency, and durable outdoor construction into a professional outdoor lighting solution. It is ideal for parks, pathways, residential communities, and urban landscape projects requiring reliable performance and attractive outdoor illumination.
