40kHz Mini Ultrasonic Dental Cleaner Stamping Tank With Mechanical Knob
2. Ceramic heaters for better heating effect.
3. Stamping tank without welding gap for better waterproof.
4. With stainless steel 304 tank and basket.
| Electronics |
Relay—remove metal filings and impurities, Potentiometer-- impurities and oil stain on moving contact, Vacuum tube parts-- Dirt and impurity on the polar plate of the electron gun, Semiconductor element--Dir on the surface of the silicon wafer and crystal wafer, Capacitor--Dirt on pins of the capacitor, Printed circuit board--Ink and oxide left during processing printed circuit board, Magnetic head--Dirt on the surface of the magnetic head. |
| Mechanical |
Bearing, gear--Metal filings and impurities left during the processing of internal and external sheath of bearing, Spring--cleaning before spring turning black, Vernier caliper, measuring tool--Metal filings and oil stain left during the processing of parts, Oil choke, oil pump--Metal filings and dirt left during the process of the inner hole of oil choke and oil pump, Screw rod, air valve, pneumatic elements--Iron filings, cutting oil and abrasive left while processing. |
| Model | Tank Size | Unit Size | Volume | Ultrasonic Power | Ultrasonic Frequency | Heating Power | Timer | Heating Temperature |
| L x W x H (mm) | L x W x H (mm) | (L) | (W) | (kHz) | (W) | (MIN) | (℃) | |
| VGT-1607 | 150x85x65 | 175x110x185 | 0.7 | 50 | 40kHz | N/A | N/A | N/A |
| VGT-1613T | 150x140x65 | 190x170x185 | 1.3L | 50 | N/A | 0-15 | N/A | |
| VGT-1620T | 150x140x100 | 190x170x220 | 2 | 50 | N/A | 0-15 | N/A | |
| VGT-1730QT | 240x140x100 | 270x170x240 | 3 | 100 | 100 | 0-20 | 20-80 | |
| VGT-1860QT | 300x155x150 | 330x180x310 | 6 | 150 | 300 | 0-20 | 20-80 | |
| VGT-1990QT | 300x240x150 | 330x270x310 | 9 | 200 | 300 | 0-20 | 20-80 | |
| VGT-2013QT | 330x300x150 | 360x330x310 | 13 | 300 | 400 | 0-20 | 20-80 | |
| VGT-2120QT | 500x300x150 | 550x330x310 | 20 | 400 | 500 | 0-20 | 20-80 | |
| VGT-2227QT | 500x300x200 | 550×330×360 | 27 | 500 | 500 | 0-20 | 20-80 |
