Single Mode Duplex Armoured Fiber Patch Cord FC/LC/SC/ST 3.0mm Prevent Rat Bites

Price Negotiable
Price: Negotiable
MOQ: 10PCS
Delivery Time: 3-5days
Brand: UNIFIBER-OEM
Product Description

Armoured fiber patch cord FC/LC/SC/ST Single Mode Duplex 3.0mm 1m to 200m Prevent Rat Bites G657A Bend Insensitive Fiber

UNIFIBER Armoured Fiber Optic Patch Cords feature a stainless-steel tube wrapped around the fibers and are designed for intrabuilding applications such as data centers that require long-term, reliable protection. These riser cables are moisture, crush, and rodent-resistant while maintaining the flexibility found in standard fiber optic cables.



Feature

Riser-Rated, PVC Jacket
Flame Retardant and Crush Resistant

Stainless Steel Armor Provides Added Durability
Ideal for Patching Backbone Trunks to High-Speed Network Devices

Bend Insensitive Fiber for Maximum Flexibility (SingleMode/Multimode/OM3/OM4/OM5)
Ceramic Ferrules for Long-Lasting Reliability and Precision Alignment



Application

Fiber LAN, WAN

CATV
FTTX, FTTB, FTTC
Optical fiber communication system



Parameters:

Connector
SC,FC,LC,ST,MU,E2000
Polishing
SM/UPC
MM/PC
SM/APC
Insertion Loss(max)
≤0.30dB
≤0.3dB
≤0.30dB
Return Loss(min)
≥50 dB
≥35 dB
≥60 dB
Tensile Strength(N)
Longterm 100;short term:200
Crush Resistance(N/100mm)
Longterm 3000;short term:5000
Durability
<0.20 dB typical change, 1000 matings
Repeatability
≤0.1dB
Storage , Operating Temperature [°C]
-40~+85
