Ptfe Coated Fiberglass Mesh Conveyor Belt High Temperature Resistance
PTFE Coated Fiberglass Mesh Conveyor Belt High Temperature Resistance
PTFE Conveyor Belts Introduction
PTFE conveyor belt , is also called PTFE Coated fiberglass mesh belt, is to use glass fiber cloth , coated with emulsion made of a kind of high temperature resistant conveyor belt , high temperature can reach 260 degrees , at the same time , high strength , corrosion resistance .
PTFE conveyor belt with a concave transition in the claw wheel.Carry out a proof, steel cable conveyor belt transverse strength is insufficient , startup , investing conveyor belt pulley cause local force is too large , lead to tear conveyor belt , take umbrella department to le le pulleys drum , can the thorough settlement of this problems .
PTFE Conveyor Belts Data Sheets
|
Code
|
Mesh size
(mm)
|
Thickness
(mm)
|
Weight
(g/m²)
|
Tensile Stength
(N/5cm)
|
NOTES
|
|
M011
|
1*1
|
0.5
|
390
|
1600*1500
|
single weft
|
|
M021
|
2*2.5
|
0.7
|
450
|
2200*1500
|
single weft
|
|
M041
|
4*4
|
1.0
|
480
|
2100*1500
|
single weft
|
|
M042
|
4*4
|
1.0
|
600
|
2100*1800
|
Double weft
|
|
M042KG
|
4*4
|
1.0
|
550
|
4100*1800
|
double weft Kevlar warp
|
|
M102
|
10*10
|
1.0
|
450
|
1100*1100
|
double weft
|
PTFE Conveyor Belt Usage
It is suitable for use of teflen conveyor belt for hot air and heat transfer conditions .
A : textile , printing and dyeing : printing drying , bleaching cloth drying , fabric shrinkage drying , non-woven cloth drying and other drying road , drying conveyor belt
B : silk screen , printing: loose dryer , offset printing press , UV series light solid machine , paper oil drying , UV drying , plastic products silk printing drying and other drying road , oven conveyor belt .
C : other items : high frequency drying , microwave drying , all kinds of food freezing and thawing , baking , packaging thermal contraction , general water cut of items fast drying , solvent ink drying chamber conduction band.
PTFE conveyor belt Package
PTFE conveyor belt workshop
