Conveyor Dryer Sludge Dewatering Belt Steel Card Interface Waste Water Treatment
Steel Card Interface Waste Water Treatment Sludge Dewatering Conveyor Dryer Belt
Polyester Sludge Dewatering Belt Introduction
Polyester Sludge Dewatering Conveyor Belt water treatment screen is widely used in wastewater treatment
paper and tissue coal mining plants and jucie pressing of grapes fruits
| No |
Thread diameter |
Density (per/cm) |
Strength (N/cm) |
Water permeablility S/5L |
Weight Kg/m2 |
Thickness mm |
Gas permeability |
|||
| Warp | Weft | Warp | Weft | Surface | Jointing | |||||
| 2470 | 0.05 | 0.70 | 24 | 9 | 2000 | 900 | 56.4 | 1.23 | 1.90 | 6130 |
| 27708 | 0.05 | 0.70 | 28 | 8.5 | 2100 | 900 | 63 | 1.53 | 2.21 | 4120 |
| 22903 | 0.05 | 0.90 | 23 | 5.5 | 2000 | 900 | 48 | 1.40 | 1.90 | 6800 |
| 16903 | 0.70 | 0.90 | 17 | 4.5 | 2200 | 900 | 38.6 | 1.70 | 2.0 | 7920 |
| 121103 | 0.90 | 1.10 | 12.5 | 3.8 | 3600 | 900 | 32.4 | 1.60 | 2.60 | 8610 |
| 26808 | 0.05 | 0.80 | 27 | 8.5 | 2100 | 900 | 60.3 | |||
Polyester Sludge Dewatering Belt Date Sheet
| Weaving Type | Model |
Thread Diameter (mm) |
Air Permeability (m3/m2h) |
||
| Warp | Weft | filled with stuff | |||
| Large Loop | 4070 | 0.9 | 1.1 | 0.9x4 | 20000x500 |
| 0.9x5 | |||||
| Medium Loop | 3868 | 0.7 | 0.9 | 0.8x3 | 18500x500 |
| 0.8x4 | |||||
| Small Loop | 3252 | 0.52 | 0.7 | 0.68x3 | 15000x500 |
Polyester Sludge Dewatering Belt Features
| It has heat shaping |
| It has high beaking elongation tolerance |
| It has high temperature resistant under 180 degree |
| This fabric belt is widely used in all kinds of industries,such as printing |
| Polyester spiral link dryer fabric belt is also used in papermaking industry |
| 100% polyester monofilament |
Polyester Sludge Dewatering Belt Advantage
1 Good permeability air permeability
2 Non-revealed sludge
3 Acid-resisting alkali-resisting heat resistance(180 °C)
4 Because of their designing structure, the sludge can be peel off easily after pigeonhole
filter so the screen are easily cleaned and have a long working time
5 Therefore they are designed specially for sludge dehydration
7 Filled or unfilled to achieve different filtration characteristics
8 Adhesive edges for lasting, economical solutions
gold benefication Paper industry-paper pulps making, sulplate pulppacking and
cardboard pulp Dryer -Textile yarn,Others -tailings disposal colliery, food medicine etc
You need to tell us what you want to filtrate what kind of equipment you are using
the filter result you are expecting we are able to provide you the right fabrics for
you accordingly or design the right fabrics for you The cloth is widely applied in the
horizontal vacuum belt filter rubber vacuum belt filter belt drier, belt filter press press
filter HVPF Vertical automatic filter press and used in the industry of power plant petroleum
chemical industry smelting mineral separation environment protection foods and pharmacy
For small quantity of polyester mesh belt we send them by courier or send by air
For big quantity of polyester mesh belt, usually ship them by sea
of course the shipment ways is decided by customers` requriement
Ususally we pack them with air bubble film and plastic bag when ship the belt by air
