KAWASAKI MAN B&W 6S50MC Cylinder Liner

Description:

MAN 6S50MC is an ultra-long stroke (stroke/cylinder diameter ratio of 4:1) compact model developed by

Danish ship B&w company to meet the needs of shipping market, pursue fast, high-power ships, reduce

the external size to obtain the maximum cargo space, and maintain high reliability.

At present. MAN B&W only launched four models of MC-C machine: S70MC-C. S60MO-C, S50MC-C and

S46MC-C, generally speaking, compared with the similar MC machine, the new MC-C machine has three

breakthroughs: increase 10% of the power output of the host; Reduce the host length square size by 10%;

Reduce the overall weight of the main machine by 10%.

As to 6S50MC Diesel Engine Cylinder Liner For KAWASAKI / MAN B&W, it has also been improved acco-

rdingly.The cylinder block eliminates the cooling water cavity, the cooling water pipe adopts the non-casting

form, which makes the casting easier, and the S50MC-C is more bold to cast the cylinder block into one with

the CAM box.

The position of the connecting surface between the cylinder block and the cylinder head is reduced. The co-

oling water jacket is simple, but there is cooling water jacket on the upper 1/3 of the cylinder sleeve. The co-

oling water jacket of the lower part was eliminated, and the thin long structure was adopted in combination

with the characteristic of ultra-long stroke.

Specifications:
