Anti Vandal Metal Momentary Push Button Switch 22mm Ring Symbol LED 5A 250V AC
22mm Ring symbol led Anti Vandal Push Button Switch 5A 250V AC Metal momentary push button switch
Product Description
- Yueshun push button switches brings you a wide range of high-quality and high cost performance. Our products has been rigorously tested against demanding industry standard. You can trust us.
- Our push button switches are tested rigorously. Each piece is tested for appearance and clicking for at least 5 times before sending .
- Latching switch, push it down, it stays down and latched in the closed position, press the button again and it releases and unlatched;
- Momentary switches are switches which only remain in their on state as long as they’re being actuated (pressed, held, etc.).
Product Specification
| Model Number | JS22F-11E/S |
| Mounting Hole | 22mm |
| Max.Switch Rating | Ith : 5A Ui : 250V AC |
| Material | Body Material : Stainless Steel |
| Button Material : Stainless Steel | |
| Contact Material : Silver Alloy | |
| Base Material : PBT | |
| The Front Shape | Flat Round Head |
| Terminal Type | Pin Termlmal( 2.8 * 0.5 MM ) |
| Switch Operation | Momentary or Latching are available |
| Contact Configuration | 1NO + 1NC or 2NO + 2NC |
| Mounting panel thickness | Momentary 1-8 mm , Latching 1-13mm |
| Operation Distance | About 0.5 mm |
| LED Parameters | Led Type : Ring Symbol |
| LED Color : Red,Green,Yellow,Orange,Blue,White,Purple or Double color mixing all Can be customized. |
|
| Led Voltage: 3V 6V 12V 24V 36V 110V 220V 360V for choose. |
|
| LED Life : More than 40,000 hours | |
| Protection Level | IP67 |
| Operating Temp |
-20℃~+55℃ |
