1590nm Single Mode Fiber Module CWDM-SFP10G-1590-10 Compatible
Cisco CWDM-SFP10G-1590-10 Compatible 10G CWDM SFP+ 1590nm 10km Transceiver Module
GVD-CW-SFP10G10-59 is a very compact 10Gb/s optical transceiver module for serial optical communication applications at 10Gb/s. The SFP+ Fiber Transceiver converts a 10Gb/s serial electrical data stream to 10Gb/s optical output signal and a 10Gb/s optical input signal to 10Gb/s serial electrical data streams. The high speed 10Gb/s electrical interface is fully compliant with SFI specification.
The high performance 1590nm cooled EML transmitter and high sensitivity APD receiver provide superior performance for Ethernet applications at up to 10km links.
Our CWDM product series
| Product catagory | Model | Wavelengths | Distance | Footprint | temprature |
| CWDM SFP 1G/2G | CWDM-SFP-xxxx | (1270nm~1610nm) | 40km | CWDM SFP | -20~70 C |
| CWDM SFP 1G/2G | CWDM-SFP-xxxx | (1270nm~1610nm) | 80km | CWDM SFP | -20~70 C |
| CWDM SFP 1G/2G | CWDM-SFP-xxxx-120 | (1270nm~1610nm) | 120km | CWDM SFP | -20~70 C |
| CWDM SFP 4.25G | CWDM-SFP4G-xxxx | (1270nm~1610nm) | 40km | CWDM SFP | -20~70 C |
| CWDM SFP 4.25G | CWDM-SFP4G-xxxx | (1270nm~1610nm) | 80km | CWDM SFP | -20~70 C |
| CWDM SFP+ 10G | CWDM-SFP10G-xxxx-10 | (1270nm~1610nm) | 10km | CWDM SFP+ | -20~70 C |
| CWDM SFP+ 10G | CWDM-SFP10G-xxxx-20 | (1270nm~1610nm) | 20km | CWDM SFP+ | -20~70 C |
| CWDM SFP+ 10G | CWDM-SFP10G-1470 | (1270nm~1610nm) | 40km | CWDM SFP+ | -20~70 C |
| CWDM SFP+ 10G | CWDM-SFP10G-1470-80 | (1270nm~1610nm) | 80km | CWDM SFP+ | -20~70 C |
| CWDM XFP 10G | CWDM-XFP10G-xxxx-10 | (1270nm~1610nm) | 10km | CWDM XFP | -20~70 C |
| CWDM XFP 10G | CWDM-XFP10G-xxxx-20 | (1270nm~1610nm) | 20km | CWDM XFP | -20~70 C |
| CWDM XFP 10G | ONS-XC-10G-xxxx | (1270nm~1610nm) | 40km | CWDM XFP | -20~70 C |
| CWDM XFP 10G | CWDM-XFP10G-xxxx-80 | (1270nm~1610nm) | 80km | CWDM XFP | -20~70 C |
| CWDM X2 10G | CWDM-X2-xxxx | (1270nm~1610nm) | 80km | CWDM X2 | -20~70 C |
| CWDM XENPAK 10G | CWDM-XENPAK-xxxx | (1270nm~1610nm) | 80km | CWDM XENPAK | -20~70 C |
"xxxx" meaning the wavelengths , example"xxxx=1310"
Features
-
Operating data rate up to 10Gb/s
-
18 Wavelength CWDM DFB LD Transmitter from 1270nm to 1610nm, with step 20nm
-
Very low EMI and excellent ESD protection
- 1610nm Wavelength
- Singlemode Fiber (SMF)
- Single 3.3V Power supply and TTL logic Interface
- Up to 20km Reach
- PIN High Sensitivity Receiver DDM
-
Duplex LC Connector Interface
-
Hot Pluggable SFP footprint
-
10GBASE-CWDM 10G Ethernet
- SONET SDH OC-192/STM-64
Advantages
- High Quality with ISO9001 , TUV , CE , FCC , UL and RoHS certificates
-
Fully product line
- 100%tested
- 3 year Warranty
- very fast delivery
Applications
-
10G Channels
-
Networking , Storage , Telecommunications
-
Hub , Switches , Routers , Servers , Network Interface Card (NICs)`
-
Other 10Gbps Networking Optical links
What we focus
We focus on all kinds of compatible optical transceiver modules , including GBIC , SFP , SFP+ , XFP , XENPAK , X2 , BIDI , CWDM,DWDM and other special transceiver modules . Our products are compatible with Cisco , Ciena , H3C , Extreme , HP , Foundry , D-link , Avaya , Alcatel , Riverstone , Enterasys , Netgear , Nortel , Juniper , Ruijie , Zyxel , Huawei , etc .
