10G 7m SFP+ Active DAC Cable SFP-10G-AC7M For Huawei 02310QPS
SFP-10G-AC7M Compatible 10G 7M SFP+ Active DAC Twinax Cable for Huawei 02310QPS
Description
SFP+ Copper Twinax (Figure 4) direct-attach cables are suitable for very short distances and offer a cost-effective way to connect within racks and across adjacent racks. Cisco offers passive Twinax cables in lengths of 1, 1.5, 2, 2.5, 3, 4 and 5 meters, and active Twinax cables in lengths of 7 and 10 meters.
The SFP+ DAC copper cable is programmed to be compatible with a wide range of Huawei network equipment for in-rack connections such as 10 Gigabit Ethernet (10 GbE) Switches, Routers, Network Interface Cards (NICs) and Network Storage Systems. It’s proven to be a cost-effective alternative to high-cost Huawei SFP-10G-AC7M 10G SFP+ 7m direct attach the copper cable.
Features
- Support for multi-gigabit data rates up to 10 Gb/s
- Hot-pluggable SFP 20PIN footprint
-
Compatible to SFF-8431,SFF-8432
- Improved Pluggable Form Factor(IPF) compliant for enhanced EMI/EMC performance
- Compatible to SFP+ MSA
- Power Consumption: <0.8W
- Temperature Range: 0~ 70 °C
Detail
| HW Compatible | SFP-10G-AC7M | Vendor Name | Gvdlink |
| Connector Type | SFP+ to SFP+ | Max Data Rate | 10Gbps |
| Minimum Bend Radius | 30mm | Wire AWG | 24AWG |
| Cable Length | 7m (22.97ft) | Jacket Material | PVC (OFNR) |
| Temperature | 0 to 70°C (32 to 158°F) | Protocols |
1x InfiniBand QDR, DDR, SDR, 10G Gigabit Ethernet, Fibre Channel |
Our HW DAC SFP 10G cables product series
| Model | Specification | Part number |
| SFP-10G-CU1M | Twinax cable Passive cable assembly 1m | 02310MUN |
| SFP-10G-CU3M | Twinax cable Passive cable assembly 3m | 02310MUP |
| SFP-10G-CU5M | Twinax cable Passive cable assembly 5m | 02310QPR |
| SFP-10G-AC7M | Twinax cable Active cable assembly 7m | 02310QPS |
| SFP-10G-AC10M | Twinax cable Active cable assembly 10m | 02310MUQ |
Applications
● 1-8G Fiber Channel and 1-10G Gigabit Ethernet
● Hub, Switches, Routers, Servers, Network Interface Card(NICs)
● Networking, Storage, Telecommunications
