7m 10G SFP+ Active Optical Cable 02311PQT HW SFP-10G-AOC7M
7m (23ft) HW SFP-10G-AOC7M Compatible 10G SFP+ Active Optical Cable 02311PQT
Description
This high-quality Huawei SFP-10G-AOC7M Compatible 10G SFP+ to SFP+ AOC (Active Optical Cable). A cost-effective solution that provides high bandwidth and transmission rates over short distances. The SFP+ Active Optical Cable (AOC) is a 10Gbps solution to10G Ethernet, and high-performance computing applications. The integrated cable transmits 10Gbps data in each direction over a loose tube fiber with distance up to100m. The AOC is SFP+ MSA compliance, low power consumption and light weight. Each AOC active fiber optic cable is 100% optically inspected and tested for compatability before shipping.
Our HW SFP 10G Active Optical cables product series
| Model | Specification | Part number |
| SFP-10G-AOC1M | Active Optical Cable assembly 1m | |
| SFP-10G-AOC3M | Active Optical Cable assembly 3m | 02311BKP |
| SFP-10G-AOC5M | Active Optical Cable assembly 5m | 02311PQS |
| SFP-10G-AOC7M | Active Optical Cable assembly 7m | 02311PQT |
| SFP-10G-AOC10M | Active Optical Cable assembly 10m | 02310QWH |
| SFP-10G-AOC20M | Active Optical Cable assembly 20m | 02310SSK |
Features
- 100% Optically Inspected and Tested to be compatible.
- 10Gb/s serial optical interface
- Support 10Gb/s transmission distance up to 100 meters with MMF
- Hot pluggable
- RoHS-6 compliance
Applications
-
10GBASE-SR Ethernet
-
4G/8G Fibre Channel
-
InfiniBand SDR/DDR/QDR
using detail in HW device
| Cable Type | Connection |
| SFP+ to SFP+ AOC cable | Scenario 1: used for 10GE optical port connection or stacking between CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. Scenarios 2: used for 10GE connection between and CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. Both ends connect to a 10GE optical port. |
| QSFP+ to QSFP+ AOC cable | Scenario 1: used for 40GE/100GE optical port connection or stacking between CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. Scenarios 2: used for 40GE/100GE optical port connection between and CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. |
| QSFP+ to 4*SFP+ AOC cable |
When a 40GE optical port is split into four 10GE optical ports: Scenario 1: used for 10GE optical port connection or stacking between CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. |
| SFP28 to SFP28 AOC cable |
Used for 25GE optical port connection or stacking between CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. Both ends connect to a 25GE optical port. |
| QSFP28 to QSFP28 AOC cable |
Used for 100GE optical port connection or stacking between CloudEngine 9800, 8800, 7800, 6800, and 5800 series switches. Both ends connect to a 100GE optical port. |
Our product line show
