40km 1310nm LC SMF Transceiver QSFP28 Mellanox QSFP28-ER4-100/112G
Mellanox QSFP28-ER4-100/112G Compatible 100GBASE-ER4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 40km DOM LC SMF Optical Transceiver Module
The Gvdlink for Mellanox QSFP28-ER4-100/112G Compatible QSFP28 Dual Rate Optical Transceiver Module is designed for use in 100GBASE Ethernet and 4x28G OTN client interfaces throughput up to 40km over single mode fiber (SMF) using a wavelength of 1310nm via duplex LC connectors. Taking BOX+FPC+PCBA separate design, it has great reliability, airtightness and heat dissipation performance. This transceiver is compliant with IEEE 802.3ba 100GBASE-ER4 and OTU4 4I1-9D1F standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as 100G Ethernet, 112G OTN OTU4, telecom, service provider applications and 5G wireless network.
Applications
- Fully compatible with almost all Mellanox devices
- Widely used on 100G/112G switches, routers, servers, NICs and other transmission equipment
- Suitable for data center, high-performance computing networks, etc
Mellanox QSFP28 100G Product series
| Mellanox Model | Description |
| MMA1L10-CR | 100GBASE-LR4 QSFP28 1310nm 10km DOM LC SMF |
| MMS1C10-CM | 100GBASE-PSM4 QSFP28 1310nm 500m DOM MTP/MPO SMF |
| MMA1B00-C100D | 100GBASE-SR4 QSFP28 850nm 100m DOM MTP/MPO MMF |
| MMA1L30-CM | 100GBASE-CWDM4 QSFP28 1310nm 2km LC SMF |
| QSFP28-EIR4-100G | 100GBASE-4WDM-10 QSFP28 1310nm 10km DOM LC SMF |
| QSFP28-ER4-100G | 100GBASE-ER4 QSFP28 1310nm 40km DOM LC SMF |
| QSFP28-LR4-100/112G | 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 10km LC SMF |
| QSFP28-LR4-100/112G-20 | 100GBASE-LR4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 20km DOM LC SMF |
| QSFP28-ER4-100/112G | 100GBASE-ER4 and 112GBASE-OTU4 QSFP28 Dual Rate 1310nm 40km DOM LC SMF |
| MMA1L10-CR-I | 100GBASE-LR4 QSFP28 1310nm 10km DOM LC SMF |
Guarantee
We provide 3 years warranty for all the optical transceivers from the date of shipment .
Our products are compatible with Cisco , Ciena , H3C , Extreme , Foundry , Mellanox , Avaya , D-link , Alcatel , Riverstone , Enterasys , Netgear , Nortel , Juniper , Ruijie , Zyxel , Huawei , etc .
