YRTC100 Rotary Table Bearing Heavy Duty Turntable Bearing Anti Friction
Price:
Negotiable
MOQ:
1 set
Delivery Time:
Negotiable
Brand:
Monton
Product Description
YRTC100 Rotary Table Bearing Heavy Duty Turntable Bearing Anti Friction
| Designation | Dimensions (mm) | Fixing holes | Threaded extraction hole | Screw tightening torque MA Nm |
||||||||||||||
| d | D | H | H1 | H2 | C | D1 max. |
J | J1 | Inner ring | Outer ring | G | Qty | ||||||
| d1 | d2 | a | Qty | d3 | Qty | |||||||||||||
| YRTC100 | 100 | 185 | 30 | 25 | 13 | 12 | 161 | 112 | 170 | 5.6 | 10 | 5 | 16 | 1.6 | 15 | M5 | 3 | 8.5 |
| Designation | Pitch t | Basic load ratings | Rigidity | Mass m =kg |
||||||||
| Quantity X t | axial | radial | bearing position | rolling element set | ||||||||
| Including retaining screws and extraction threads | dyn. Ca N |
stat.C0a N |
dyn. Cr N |
stat. C0r N |
axial CaL kN/µm |
radial CrLkN/µm |
Tilting rigidity Nm/mrad |
axial CaL kN/µm |
radial CrL kN/µm |
Tilting rigidity CkLkNm/mrad |
||
| YRTC100 | 18 x 20° |
105 000 |
455 000 |
500 00 |
88000 | 2.65 | 2.25 | 6.6 | 8.7 | 3.7 | 23.5 | 3.65 |
