Reflectorless Surveying Equipment Sokkia Im52 Total Station 500m Range
Price:
Negotiable
MOQ:
1 pcs
Delivery Time:
3-5 days
Brand:
Sokkia
Product Description
Sokkia japan IM52 types of estacion total station Reflectorless surveying equipment
| MODEL | iM-52 |
| Magnification / Resolving power | 30x / 2.5” |
| Length | 171mm (6.7in.) |
| Objective aperture | 45mm |
| Minimum focus | 1.3m (4.3ft.) |
| Minimum Display | 1"/5" |
| Accuracy | 2” |
| Dual-axis compensator | Dual-axis liquid tilt sensor |
| Collimation compensation | On/Off (selectable) |
| Reflectorless | 0.3 to 500m |
| Reflective sheet | 1.3 to 500m |
| Mini prisms | 1.3 to 2,500m |
| One prism | 1.3 to 4,000m |
| Operating system | Linux |
| Control panel location | On both faces |
Key featrues
* Reflectorless Upto 500 meter
* Optional Bluetooth connectivity
* 50,000-point internal memory
* Magnification: 30x
* Dual-axis compensation
* IP66 dustproof and water resistant
* Battery life up to 14 hours
* Reflectorless Upto 500 meter
* Optional Bluetooth connectivity
* 50,000-point internal memory
* Magnification: 30x
* Dual-axis compensation
* IP66 dustproof and water resistant
* Battery life up to 14 hours
Sokkia IM52 Perfect for entry-level site layout and surveying, the Sokkia iM-50 Series Reflector-less Total Station is a smart
measuring device that offers reliable and accurate results with a friendly price. The Sokkia iM-50 features a reflector less range up to 1,640 feet and up to 13,123 feet with a single prism. Featuring an advanced angle accuracy, it also comes with an integrated Bluetooth connectivity option and an internal antenna for a cable-free operation.
This Sokkia total station features a coaxial red laser with EDM beam technology and comes with a 30x magnification with 2.5-inch resolving power. It is provided with a ±6-degree range dual-axis compensation that allows reliable measurements on any terrain. Also, it includes an SDRbasic on-board software and a 50,000-point internal memory for a smooth surveying operation.
With an IP66 rating, the Sokkia iM-50 is total dust proof and water resistant. It features a graphic LCD display that has a 28-key alphanumeric keyboard with back-light. In addition, it uses a rechargeable Li-ion battery that operates up to 14 hours which is the best companion for a long work day.
Sokkia IM52 is upgraded version of Sokkia CX52 Total Station
