3000 PSI API 16A Oil Blowout Preventer Blowout Prevention System Alloy Steel Forging
Oil & Gas Well Polished Rod BOP Of Size 2 7/8 “ x 3000 PSI API 16A
Polished rod bop is a kind of sucker rod bop, which is pressure control equipment in oilfield operation, and the BOP is used to seal the sucker-rod pump polish rod to prevent oil and gas Leakage and conformed with API 16A. When installed on the top tubing or x-mas tree, the Sucker Rod BOPs are to give positive protection against blow outs, when operating with sucker rods / polished rods in workover operations, by providing positive seal around the sucker rod/polish rod.Also, BOP shall be dressed with 3/4” rams & all other rams sizes shall be supplied as accessories.
Structural features of Polished rod BOP
* The Polished rod BOP is reasonable designed according to API 16A
* The Polished Rod BOP is with simple structure for convenient operation
* The polished rod bop has reliable sealing features and long service life.
* As the necessary tools on the oilfield, the polished rod BOP meet the standards of all kinds of rod seal. It’s a kind of
Specification of 2 7/8" x 3000 psi Polished rod BOP
|
POLISHED ROD SIZE
|
1-1/2” |
|
RAM SIZE
|
1-1/2” |
|
BORE SIZE
|
2-9/16” |
|
PRESSURE RATING
|
3000 PSI |
|
TEMPERATURE RATING
|
100 °C |
| TOP CONNECTIONS |
|
|
BOTTOM CONNECTIONS
|
SAME AS TOP CONNECTIONS |
|
|
About JC Wellhead
Jingcheng Petroleum Machinery Manufacturing Co.,Ltd was established in 2008 and certified by API, YCJC is specialized in design and manufacturing of the oilfield wellhead equipment according to API specification. Now, YCJC is a registered supplier for CNPC, GWDC, CCDC in China and YCJC exports various of wellhead equipment to abroad and enjoy the good reputation.
We are able to manufacture and supply the wellhead equipment, well surface testing equipment, well flow control equipment according to API 6A, API 16A, and API 16C. The main products include wellhead Christmas tree, casing head, tubing head, casing spool, tubing spool, Gate valve, Choke valve, Check valve, , VR plug, Tubing hanger, casing hanger, Running tool, Wear bushing, double studded adpater flange,spacer spool / riser spool, flange adapter, union flange, Hammer union, Elbow, swivel joint, block cross, Block Tee, companion flange, instrument flange, weldneck flange, FC gate, FC seat, FC stem, API Clamp, API Clamp Hub, vairous high pressure maifold and wellhead straight pipes etc.
