Flexible Choke Kill API 16C Stainless Steel Armored Hose
Flexible Choke and Kill Hose for Sour Gas Well API 16C 5000 psi
The flexible choke & kill hose is conformed with API 16C standard. The Conflex hose is featured with armored, thermal insulation, anti-flaming, high pressure resistance and fire resistance.The inner wall of Flexible Choke and Kill Line is resistant to high abrasion. The Flexible choke and kill hose can be used for flexible connection between the riser and choke manifold & kill manifold. It is applicable as connection part when drill platform, semi-submersible drilling vessel or drilling vessel moves relatively and for adjustment of the installation variance of the drilling rig.
Technical parameter of flexible choke and kill hose
| Hose ID | 2″, 2-1/2″, 3″, 3-1/16″, 3-1/2″, 4″ |
| Working Pressure | 5000PSI(5K), 10000PSI(10K), 15000PSI(15K) |
| Length | 30feet, 60feet, as per customers’ requirements |
| Working Temperature Range: | -20°C ~ +121 °C |
| End Fittings/End Connections/Couplings | API Flanges, Hammer Union, NPT Thread, API Male End, Unibolt, Clamp Connection Type or as per customers requirements |
| Tube(Lining) | Nitrile Rubber, Fluoroelastomer. Featuring oil resistance, abrasion resistance, Corrosion Resistance, and up to 20% H2S. |
| Reinforcement: | 2-8 layers of single high strength steel wire spiral. |
| Cover: | Neoprene, featuring Oil Resistance, Abrasion Resistance, Weather Proof and Anti-Aging. |
| Fire-Resistant Layer: | Fire-Resistant Synthetic Rubber |
| Outer Protective Layer: | Stainless Steel Sheathed/Armored. |
| External Braided Steel Wire Layer | braided by stainless steel wire |
| Options/Attachment: | Accessories such as safety clamps and chain/hose lift eyes are available upon request. |
| Pressure Test: | Each hose is tested at 22500psi for 15 minutes. |
Detailed Specification of Flexible Hose
Flexible Choke and Kill Hose for Sour gas well as API 16C specification with the following:
Working Pressure: 5000psi
OD 6.25”
ID:4”
Grade:D
Length:60’
Couplings: 4 1/16” Flange End both sides
External Armored Layer Stainless steel
Operating Temperature -18 to 121C
With Hose Lifting Eyes
About JC Wellhead
JC Petroleum Equipment Factory manufactures and supplier the various wellhead equipment andrelated parts to meet different requirement in oilfield service operation. The wellhead equipment are conformed with API 6A and wellhead choke manifold is according to API16C specification, and applied for high pressure and high temperature working condition.
In 2012, JC wellhead jointed with ZZ TOP Oil Tools, and found the office in Xi'an mainly engaged in abroad marketing, through these years of efforts, our wellhead equipment is exported to many countries, such as Thailand, UAE, Iran, Brazil, Argentina, USA etc. and enjoyed good reputation from the customers.
With profession engineers we also offer the R&D service to the clients who have special requirements in the oilfield drilling operation and production operation.The wellhead equipment we manufacture and supply include casing head, tubing head, casing spool, tubing spool, Gate valve, Choke valve, Check valve, X-mas tree, VR plug, Tubing hanger, casing hanger, Running tool, Wear bushing, spacer spool, flange adapter, union flange, Hammer union, Elbow, swivel joint, block cross, Block Tee, companion flange, instrument flange, weldneck flange, FC gate, FC seat, FC stem, API Clamp, API Clamp Hub
YCJC will constantly insist on the innovation of products, technologies and system and strive for providing the excellent products and services for our customers. We are sincerely welcome you to work together.
