5052 H32 Marine Grade Aluminum Plate 34mm Thickness Rorrosion Resistance Excellent Formability
Price:
Negotiable
MOQ:
1 metric ton
Delivery Time:
35 days
Brand:
HUANYU
Product Description
5052 H32 Marine Grade Aluminum Plate 34mm Thickness Rorrosion Resistance Excellent Formability
5052 H32 Marine Grade Aluminum Sheets Plates
5052 Aluminum is one of the higher strength non-heat treatable alloys
Alloy 5052 has excellent characteristics with a high fatigue strength it is used for structures which are subject to excessive vibrations.
As 5052 also has excellent corrosion resistance, especially in marine atmospheres and is therefore commonly used in boats, marine components, fuel and oil tubing.
5052-H32 can be readily welded using all the common welding techniques. 5052 has the best welding characteristics of all the aluminums.
| 5052 Aluminum Alloy Chemical Composition Limits | |||||||||
| Weight% | Al | Cu | Si | Fe | Mn | Mg | Zn | Cr | Others |
| 5052 | Bal | 0.10 max | 0.25 max | 0.40 max | 0.10 max | 2.2 / 2.8 | 0.10 max | 0.15 / 0.35 max | 0.05 max (each) 0.15 (total) |
5052 Marine Grade Aluminum Plate Typical Mechanical Properties
| Material | Temper | Tensile Strength (ksi) | Yield Strength (ksi) | Elongation % in 2" | min bend radius (90° cold forming) |
| 5052 Sheet 0.064" thick |
5052-0 | 25-31 | 9.5 | 19 | 0 |
| 5052 Sheet 0.064" thick |
5052-H32 | 31-38 | 23 | 7 | 1t |
| 5052 Sheet 0.064" thick |
5052-H34 | 34-41 | 26 | 6 | 1 1/2 t |
