2219 T6 Aluminum Forging Parts Ultrasonic Tested Military Usage
Price:
Negotiable
MOQ:
1 METRIC TON
Delivery Time:
3~4 WEEKS
Brand:
HUANYU
Product Description
Ultrasonic Tested Military Usage 2219 T6 Aluminum Forging Parts
Technical Data Sheet
Aluminium Alloy 2219 is a high strength alloy which combines good machinability and good mechanical properties. 2219 is useful over a temperature range of -452°F to 600°F, is readily weldable and has good fracture toughness. In the T8 condition it is resistant to stress corrosion cracking.
Aluminium 2219 is typically used in a range of aerospace applications such as high temperature structural applications including space booster and fuel tanks.
| Chemical Composition Limits | |||||||||||
| Weight% | Al | Si | Fe | Cu | Mn | Mg | Zn | Ti | Others | V | Zn |
| Alloy 2219 | Bal | 0.20 max | 0.30 max | 5.80-6.80 | 0.20-0.40 | 0.02 max | 0.10 max | 0.02-0.10 | 0.050 each 0.15 total |
0.05-0.15 | 0.10-0.25 |
Features:
Alloy temper: 2219 T6
Specification: L 800mm x W 600mm x 400mm
Introduction of mechanical properties:
Tensile strength: >410MPA
Yield strength: >330MPA
Elongation:> 8%
Specification: L 800mm x W 600mm x 400mm
Introduction of mechanical properties:
Tensile strength: >410MPA
Yield strength: >330MPA
Elongation:> 8%
