Durable PP Hollow Sheet Extrusion Line Building Construction Formwork Application
PP Hollow Building Formwork Production Line PP Construction Formwork Machine
PP hollow board Introduction
The new hollow plastic building formwork is light in weight, easy to support and remove the mould, has low labor intensity in transportation operation, high construction efficiency, safety and reliability, no moisture absorption, corrosion resistance, acid and alkali resistance, and the surface is smooth, smooth, and does not require brushing and demoulding agent.
The waste board and scraps after the use of the hollow plastic building formwork can be recycled, which saves cost and reduces pollution.
The comprehensive use cost of the new hollow plastic building template can save more than 30% than the traditional wood formwork.
PP building templates extrusion production line is successfully developed by our company to absorb and digest foreign advanced extrusion technology and independent innovation. The plate thickness range can be made to 14-18mm, and the plate width can be customized according to customer's requirements of 915mm-1220mm. Its production surface is smooth and clean. , Small size error, with nail, planing, corrosion resistance, flame retardant and many other advantages.
Composition of PP Hollow Building Template Production Line
| No | Name | Quantity |
| 1 | SJ120 single screw vented extruder | One set |
| 2 | SJ65 single screw vented extruder | One set |
| 3 |
Hydraulic screen exchanger + Hydraulic Pressure station |
Two Sets |
| 4 | distributor ( ABA ) | One set |
| 5 | Mould | One set |
| 6 | vacuum calibrating table | One set |
| 7 | Six-roller haul-off unit(the first haul-off) | One set |
| 8 | cooling bracket | two sets |
| 9 | Two-roller haul-off unit (Second haul-off ) | One set |
| 10 | transverse cutter | One set |
| 11 | Conveyor | One set |
| 12 | Stacker | One set |
| 13 | Electric Control System | One set |
| 14 | Feeding Device | Two sets |
Product Specifications
1. 1.2cm*91.5cm*183cm,1.2cm*122cm*244cm
2. 1.4cm*91.5cm*183cm,1.4cm*122cm*244cm
3. 1.6cm*91.5cm*183cm,1.6cm*122cm*244cm
4. 1.8cm*91.5cm*183cm,1.8cm*122cm*244cm
Application
PP new hollow building formwork production line This unit has a single screw extruder consisting of hydraulic screen changer, mold, primary traction machine, annealing furnace, cooling section, secondary traction machine, cross cutting machine and conveyor. In the industry, the initial O-shaped hollow structure was changed to the m-shaped, V-shaped, N-shaped, and well-shaped type, and finally changed to a grid type. The grid-shaped structure is accepted by the market in terms of material usage and structural properties. The surface of the produced product is smooth and has small dimensional error, and has many advantages such as nailing, planing, corrosion resistance and flame retardancy.
