Li-SOCL2 Battery ER14250M Lithium Primary Battery 3.6V 800mAh High Energy 1/2AA High for Radio Communications

• Table Operating Voltage: excellent stability. On the high voltage platform where the voltage is almost unchanged, the output capacity is still more than 90%.
• Wide Temperature Range: can be operated in the temperature of -60°C ~ +85°C.
• Long Storage Life: self-discharge rate is less than 1%.
• Higer Capacity, the energy density can reach to 680wh/kg.
• High Voltage:open circuit voltage of single cell is 3.65V, operating voltage varies with the load from 3.3V~3.6V.
• The shelf life is more than 10 years when stored in normal temperature, due to its hermetically sealed structure which reduces the leakage greatly.

• AMR utility metering (Electricity, Gas, Water, Heat meter)
• Alarms and security wireless devices Mobile asset tracking,
• GPS, Tracking, RFID, Emergency location transmitters beacons (ELTs, EPIRBs)
• Seismic equipement, CNC maching, taxi meters, telephone set,
• Underwater weapon, military communication transmitter-receive,
• Portable communication equipment, TPMS







     ​

Model	Size	Nominal Voltage (V)	Nominal Capacity (mAh)	Max. Continuous Current (mA)	Max. Pulse Current (mA)	Operation Temperature	Dimension (mm)	Weight (g)	Data Sheet
ER14250M	1/2AA	3.6	800	200	300	-60°C ~ 85°C	φ14.5*26.3	11
ER14335M	2/3AA	3.6	1300	200	400	-60°C ~ 85°C	φ14.5*33.7	14
ER14505M	AA	3.6	2200	500	1000	-60°C ~ 85°C	φ14.5*50.5	21
ER17335M	2/3A	3.6	1900	500	1000	-60°C ~ 85°C	φ17*33.8	20
ER17505M	A	3.6	2700	1000	2000	-60°C ~ 85°C	φ17*50.5	29
ER18505M	A	3.6	3500	1000	2000	-60°C ~ 85°C	φ18.8*50.5	33
ER26500M	C	3.6	6500	1500	2500	-60°C ~ 85°C	φ26.2*50	57
ER34615M	D	3.6	14500	2000	4000	-60°C ~ 85°C	φ34.2*61.5	110
