Li-SOCL2 Battery ER26500S High Temperature Battery 3.6V 6000mAh for Water Meter, GPS

• Higer & stable working voltage. Nominal voltage is 3.0V, 90% capacity output under the stable voltage.
• Widely using temperature range, can be operated in -60°C ~ +150°C.
• Excellent storage life and reliability. With low self-discharge, yearly self-discharge rate ≤ 1%.
• The battery can be stored at room temperature for more than 10 years beacasue of its stainess steel and metal-glass sealed gas-tight welding structure.
• Forte batteries are environmentally friendly and pollutant fee power, it's W/O mercury,cadmium,lead and other heavy metals.

• Petroleum Industry: downhole high temperature EPG, flow meters, LWD/MWD and other downhole high temperature instruments(processing and battery racks can be done as required)
• Automobile Industry: TPMS, diesel engine cylinder monitors and so on
• Geothermy Industry: High temperature inspection instrument
• Military uses and other battery-powered devices used in high temperature







     ​

Model	Size	Nominal Voltage (V)	Nominal Capacity (mAh)	Max. Continuous Current (mA)	Max. Pulse Current (mA)	Operation Temperature	Dimension (mm)	Weight (g)	Data Sheet
ER14250S	1/2AA	3.6	680	50	100	-60°C~150°C	φ15.2*25.6	11
ER14505S	AA	3.6	2000	100	200	-60°C~150°C	φ15.2*50.5	20
ER18505S	A	3.6	2200	150	200	-60°C~150°C	φ19.5*51.5	34
ER26500S	C	3.6	6000	150	300	-60°C~150°C	φ27.2*50	55
ER34615S	D	3.6	13000	100	200	-60°C~150°C	φ35.2*61.5	105
ER261020S	CC	3.6	13000	200	400	-60°C~150°C	φ26.8*100	102
ER341245S	DD	3.6	25000	400	800	-60°C~150°C	φ35.2*125	220



Note:

1.Store the battery in cool and dry place where without direct sunlight and keep away from intense heat like fires or liquids.

2.This battery is NOT rechargeable.

3.This battery can be customized as you want in logo, color, package and battery packs with wires or pins or connectors, just send inquiry to us, and get your ideal battery.





FAQ

Q1: Before order, can I have samples for testing?

A: Yes, we can provide you samples for testing firstly.



Q2: Do you test all your goods before delivery?

A: Yes, we have 100% test before delivery.

Q3: How to proceed an order?

A: 1. Contact our service & let us know your requirements or application.

2. We quote according to your requirements or our suggestions.



Q4: What is MOQ?

A: Low MOQ, 1pc for sample checking is available.



Q5: What is your payment and delivery items & time?

A: 1. Payment items: By T/T, 30% for deposit, and balance all before shipment.

For small amount, we also accept payment via PayPal.

2. Delivery Items: we can ship the batteries by
sea, by air, by UPS, DHL, TNT, FEDEX and some special line.

3. Delivery time: Generally, it will take 7 to 15 days after receiving
your advance payment.

Sample : 7 days.

Big Order: 5-15days. The specific delivery time depends on the items and the quantity of
your order.
