Li-SOCL2 Battery ER18505S High Temperature Battery 3.6V 2200mAh for Water Meter, GPS

• Higer & stable working voltage. Nominal voltage is 3.0V, 90% capacity output under the stable voltage.
• Widely using temperature range, can be operated in -60°C ~ +150°C.
• Excellent storage life and reliability. With low self-discharge, yearly self-discharge rate ≤ 1%, stainless steel container and hermetically glass-to-metal sealing structure to make sure the battery could be stored more than 10 years in the room temperature.
• Forte batteries are environmentally friendly and pollutant fee power, it's W/O mercury,cadmium,lead and other heavy metals.

• Petroleum Industry: downhole high temperature EPG, flow meters, LWD/MWD and other downhole high temperature instruments(processing and battery racks can be done as required)
• Automobile Industry: TPMS, diesel engine cylinder monitors and so on
• Geothermy Industry: High temperature inspection instrument
• Military uses and other battery-powered devices used in high temperature





     ​

Model	Size	Nominal Voltage (V)	Nominal Capacity (mAh)	Max. Continuous Current (mA)	Max. Pulse Current (mA)	Operation Temperature	Dimension (mm)	Weight (g)	Data Sheet
ER14250S	1/2AA	3.6	680	50	100	-60°C~150°C	φ15.2*25.6	11
ER14505S	AA	3.6	2000	100	200	-60°C~150°C	φ15.2*50.5	20
ER18505S	A	3.6	2200	150	200	-60°C~150°C	φ19.5*51.5	34
ER26500S	C	3.6	6000	150	300	-60°C~150°C	φ27.2*50	55
ER34615S	D	3.6	13000	100	200	-60°C~150°C	φ35.2*61.5	105
ER261020S	CC	3.6	13000	200	400	-60°C~150°C	φ26.8*100	102
ER341245S	DD	3.6	25000	400	800	-60°C~150°C	φ35.2*125	220
