CR34615 LiMnO2 Battery
Li-MnO2 Battery CR34615 Lithium Primary Battery 3.0V 12000mAh D Size for Water Meter, GPS
- High voltage: open circuit voltage is above 3.0V, operation voltage can reach 2.8V~3.2V.
- High energy density: battery enery density can reach 400wh/kg.
- High capacity, steady performance, stable discharge voltage and non-voltage hysteresis
- Wide temperature range: can be used between -40°C ~ +85°C
- Low battery self-discharge: annual reduction rate of less than 1% of the capacity
- A fully sealed structure, significantly reduced the rate of cell leakage, batteries can be stored at room temperature for more than 10 years
- Good battery safety performance, reliablibility, non-pullution, green power
- Different design of power type and energy type batteries are offered to meet different operating requirements.
- Intelligent IC card, water meter, ammeter, gas meter, camera, camcorder, PC computer, RAM, CMOS memory backup power supply, radio communications, seismic inspection instrument, military communication transmitter-receiver, underwater weapons, medical instruments, facilities of defence and security, portable communication equipment, time counter, number counter and so on
| Model | Size |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Max. Continuous Current (mA) |
Max. Pulse Current (mA) |
Operation Temperature |
Dimension (mm) |
Weight (g) |
Data Sheet |
| CR14250 | 1/2AA | 3.0 | 600 | 500 | 1500 | -40°C ~ 85°C | φ14.5*25.5 | 10 | |
| CR14335 | 2/3AA | 3.0 | 800 | 1000 | 2000 | -40°C ~ 85°C | φ14.5*33.5 | 14 | |
| CR14505 | AA | 3.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | φ14.5*50.5 | 21 | |
| CR2 | 3.0 | 850 | 1000 | 2000 | -40°C ~ 85°C | φ15.5*27.5 | 13 | ||
| CR123A | 2/3AA | 3.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | φ17*33.5 | 20 | |
| CR17450 | 3.0 | 2000 | 1500 | 3000 | -40°C ~ 85°C | φ17*45.5 | 26 | ||
| CR17505 | 3.0 | 2300 | 1500 | 3000 | -40°C ~ 85°C | φ17*50.5 | 30 | ||
| CR18505 | A | 3.0 | 2500 | 2000 | 3000 | -40°C ~ 85°C | φ18.5*50.5 | 35 | |
| CR26500 | C | 3.0 | 5400 | 2000 | 3000 | -40°C ~ 85°C | φ26*50.5 | 62 | |
| CR34615 | D | 3.0 | 12000 | 2000 | 3000 | -40°C ~ 85°C | φ34*61.5 | 125 | |
| CR-P2 | 6.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | 34*19.5*35.8 | 42 | ||
| 2CR5 | 6.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | 34*17*45 | 43 | ||
| CR9V | 9.0 | 800 | 500 | 1000 | -40°C ~ 85°C | 17*26*48.8 | 40 | ||
| CR14250SE | 1/2AA | 3.0 | 900 | 8 | 70 | -40°C ~ 85°C | φ14.5*25.5 | 11 | |
| CR14335SE | 2/3AA | 3.0 | 1100 | 9 | 80 | -40°C ~ 85°C | φ14.5*33.5 | 16 | |
| CR14505SE | AA | 3.0 | 1800 | 10 | 100 | -40°C ~ 85°C | φ14.5*50.5 | 22 | |
| CR15270SE | 3.0 | 1000 | 9 | 80 | -40°C ~ 85°C | φ15.5*27.5 | 13 | ||
| CR17335SE | 2/3AA | 3.0 | 1800 | 10 | 100 | -40°C ~ 85°C | φ17*33.5 | 22 | |
| CR17450SE | 3.0 | 2400 | 15 | 150 | -40°C ~ 85°C | φ17*45.5 | 28 | ||
| CR17505SE | 3.0 | 2700 | 15 | 150 | -40°C ~ 85°C | φ17*50.5 | 30 | ||
| CR18505SE | A | 3.0 | 3000 | 20 | 200 | -40°C ~ 85°C | φ18.5*50.5 | 38 |
Caution: Do not make the battery short-circuit, Charge ,press, dissemble ,burn or forcibly it; Do
not use new and used batteries together or mix different types of batteries; Do not reverse the positive and negative pole of battery while using it. Do not solder directly on the battery.
