2/3AA CR14335SE LiMnO2 Battery 1100mAh Lithium Primary Battery
CR14335SE Lithium Primary Battery 3.0V 1100mAh 2/3AA Size for Water Meter, GPS
- High voltage: open circuit voltage is above 3.0V, operation voltage can reach 2.8V~3.2V.
- High energy density: battery enery density can reach 400wh/kg.
- High capacity, steady performance, stable discharge voltage and non-voltage hysteresis
- Wide temperature range: can be used between -40°C ~ +85°C
- Low battery self-discharge: annual reduction rate of less than 1% of the capacity
- A fully sealed structure, significantly reduced the rate of cell leakage, batteries can be stored at room temperature for more than 10 years
- Good battery safety performance, reliablibility, non-pullution, green power
- Different design of power type and energy type batteries are offered to meet different operating requirements.
- Gas meter, ammeter, walkman, CD, MD machine, electric shaver,
- Electric toys, wireless microphone, calculator, smoke Alarm,
- Sanitary ware sensor, electronic doorbell, electronic safe, MP3,
- Electronic dictionary, electronic notebook
- Cameras, digital cameras, cameras, night vision, LED flashlights,
- Electronic patrol rods, LED display, LED electronic desk lamp,
- Intelligent instruments, luminous drift, IC card water meter,
| Model | Size |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Max. Continuous Current (mA) |
Max. Pulse Current (mA) |
Operation Temperature |
Dimension (mm) |
Weight (g) |
Data Sheet |
| CR14250 | 1/2AA | 3.0 | 600 | 500 | 1500 | -40°C ~ 85°C | φ14.5*25.5 | 10 | |
| CR14335 | 2/3AA | 3.0 | 800 | 1000 | 2000 | -40°C ~ 85°C | φ14.5*33.5 | 14 | |
| CR14505 | AA | 3.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | φ14.5*50.5 | 21 | |
| CR2 | 3.0 | 850 | 1000 | 2000 | -40°C ~ 85°C | φ15.5*27.5 | 13 | ||
| CR123A | 2/3AA | 3.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | φ17*33.5 | 20 | |
| CR17450 | 3.0 | 2000 | 1500 | 3000 | -40°C ~ 85°C | φ17*45.5 | 26 | ||
| CR17505 | 3.0 | 2300 | 1500 | 3000 | -40°C ~ 85°C | φ17*50.5 | 30 | ||
| CR18505 | A | 3.0 | 2500 | 2000 | 3000 | -40°C ~ 85°C | φ18.5*50.5 | 35 | |
| CR26500 | C | 3.0 | 5400 | 2000 | 3000 | -40°C ~ 85°C | φ26*50.5 | 62 | |
| CR34615 | D | 3.0 | 12000 | 2000 | 3000 | -40°C ~ 85°C | φ34*61.5 | 125 | |
| CR-P2 | 6.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | 34*19.5*35.8 | 42 | ||
| 2CR5 | 6.0 | 1400 | 1500 | 3000 | -40°C ~ 85°C | 34*17*45 | 43 | ||
| CR9V | 9.0 | 800 | 500 | 1000 | -40°C ~ 85°C | 17*26*48.8 | 40 | ||
| CR14250SE | 1/2AA | 3.0 | 900 | 8 | 70 | -40°C ~ 85°C | φ14.5*25.5 | 11 | |
| CR14335SE | 2/3AA | 3.0 | 1100 | 9 | 80 | -40°C ~ 85°C | φ14.5*33.5 | 16 | |
| CR14505SE | AA | 3.0 | 1800 | 10 | 100 | -40°C ~ 85°C | φ14.5*50.5 | 22 | |
| CR15270SE | 3.0 | 1000 | 9 | 80 | -40°C ~ 85°C | φ15.5*27.5 | 13 | ||
| CR17335SE | 2/3AA | 3.0 | 1800 | 10 | 100 | -40°C ~ 85°C | φ17*33.5 | 22 | |
| CR17450SE | 3.0 | 2400 | 15 | 150 | -40°C ~ 85°C | φ17*45.5 | 28 | ||
| CR17505SE | 3.0 | 2700 | 15 | 150 | -40°C ~ 85°C | φ17*50.5 | 30 | ||
| CR18505SE | A | 3.0 | 3000 | 20 | 200 | -40°C ~ 85°C | φ18.5*50.5 | 38 |
Note:
1.Store the battery in cool and dry place where without direct sunlight and keep away from intense heat like fires or liquids.
2.This battery is NOT rechargeable.
3.This battery can be customized as you want in logo, color, package and battery packs with wires or pins or connectors, just send inquiry to us, and get your ideal battery.
