13000mAh High Temperature Lithium Battery ER261020S CC Size
High Temperature Lithium Battery ER261020S 3.6V 13000mAh for TPMS, EPG, LWD
Forte offered the high temperature Li-SOCL2 batteries. Those batteries use different material and technique which are different from the standard batteries. High temperature batteries used special steel container and cover with high temperature structure, so Forte high temperature batteries don't have discharge, drum bulge & bottom, explosion, burning phenomenon problem. It's a safety power solution.
Feature
- Higer & stable working voltage. Nominal voltage is 3.0V, 90% capacity output under the stable voltage.
- Widely using temperature range, can be operated in -60°C ~ +150°C.
- Excellent storage life and reliability. With low self-discharge, yearly self-discharge rate ≤ 1%, stainless steel container and hermetically glass-to-metal sealing structure to make sure the battery could be stored more than 10 years in the room temperature.
- Forte batteries are environmentally friendly and pollutant fee power, it's W/O mercury,cadmium,lead and other heavy metals.
Application
- Petroleum Industry: downhole high temperature EPG, flow meters, LWD/MWD and other downhole high temperature instruments(processing and battery racks can be done as required)
- Automobile Industry: TPMS, diesel engine cylinder monitors and so on
- Geothermy Industry: High temperature inspection instrument
- Military uses and other battery-powered devices used in high temperature
About Wuhan Forte
Wuhan Forte Battery Co. is established in the forefront of the production of lithium battery technology,gather the authoritative of experts engage in the lithium thionyl chloride battery(Li-SOCL2) and lithium manganese dioxide battery(Li-MnO2) from around the world, to make Research & Development, to improve production system and product promotion.
Product List
| Model | Size |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Max. Continuous Current (mA) |
Max. Pulse Current (mA) |
Operation Temperature |
Dimension (mm) |
Weight (g) |
Data Sheet |
| ER14250S | 1/2AA | 3.6 | 680 | 50 | 100 | -60°C~150°C | φ15.2*25.6 | 11 | |
| ER14505S | AA | 3.6 | 2000 | 100 | 200 | -60°C~150°C | φ15.2*50.5 | 20 | |
| ER18505S | A | 3.6 | 2200 | 150 | 200 | -60°C~150°C | φ19.5*51.5 | 34 | |
| ER26500S | C | 3.6 | 6000 | 150 | 300 | -60°C~150°C | φ27.2*50 | 55 | |
| ER34615S | D | 3.6 | 13000 | 100 | 200 | -60°C~150°C | φ35.2*61.5 | 105 | |
| ER261020S | CC | 3.6 | 13000 | 200 | 400 | -60°C~150°C | φ26.8*100 | 102 | |
| ER341245S | DD | 3.6 | 25000 | 400 | 800 | -60°C~150°C | φ35.2*125 | 220 |
