ER14505S Cylindrical Lithium Batteries 2000mAh LiSOCl2 Battery
Cylindrical Lithium Battery ER14505S ER Battery for Diesel Engine Cylinder Monitors
Forte offered the high temperature Li-SOCL2 batteries. Those batteries use different material and technique which are different from the standard batteries. High temperature batteries used special steel container and cover with high temperature structure, so Forte high temperature batteries don't have discharge, drum bulge & bottom, explosion, burning phenomenon problem. It's a safety power solution.
Specification
| Model | ER14505S |
| Size | AA |
| Nominal Voltage | 3.6V |
| Nominal Capacity | 2000mAh |
| Max. Constant Current | 100mAh |
| Max. Pulse Current | 200mAh |
| Dimension | φ15.2*50.5mm |
| Weight | 20g |
Feature
- Higer & stable working voltage. Nominal voltage is 3.0V, 90% capacity output under the stable voltage.
- Widely using temperature range, can be operated in -60°C ~ +150°C.
- Excellent storage life and reliability. With low self-discharge, yearly self-discharge rate ≤ 1%, stainless steel container and hermetically glass-to-metal sealing structure to make sure the battery could be stored more than 10 years in the room temperature.
- Forte batteries are environmentally friendly and pollutant fee power, it's W/O mercury,cadmium,lead and other heavy metals.
Application
- Petroleum Industry: downhole high temperature EPG, flow meters, LWD/MWD and other downhole high temperature instruments(processing and battery racks can be done as required)
- Automobile Industry: TPMS, diesel engine cylinder monitors and so on
- Geothermy Industry: High temperature inspection instrument
- Military uses and other battery-powered devices used in high temperature
Product List
| Model | Size |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Max. Continuous Current (mA) |
Max. Pulse Current (mA) |
Operation Temperature |
Dimension (mm) |
Weight (g) |
Data Sheet |
| ER14250S | 1/2AA | 3.6 | 680 | 50 | 100 | -60°C~150°C | φ15.2*25.6 | 11 | |
| ER14505S | AA | 3.6 | 2000 | 100 | 200 | -60°C~150°C | φ15.2*50.5 | 20 | |
| ER18505S | A | 3.6 | 2200 | 150 | 200 | -60°C~150°C | φ19.5*51.5 | 34 | |
| ER26500S | C | 3.6 | 6000 | 150 | 300 | -60°C~150°C | φ27.2*50 | 55 | |
| ER34615S | D | 3.6 | 13000 | 100 | 200 | -60°C~150°C | φ35.2*61.5 | 105 | |
| ER261020S | CC | 3.6 | 13000 | 200 | 400 | -60°C~150°C | φ26.8*100 | 102 | |
| ER341245S | DD | 3.6 | 25000 | 400 | 800 | -60°C~150°C | φ35.2*125 | 220 |
Note:
1.Store the battery in cool and dry place where without direct sunlight and keep away from intense heat like fires or liquids.
2.This battery is NOT rechargeable.
3.This battery can be customized as you want in logo, color, package and battery packs with wires or pins or connectors, just send inquiry to us, and get your ideal battery.
Our Service
1. We provide various type single cell battery.
2. Battery assembly supported,battery with solder tabs, wires and connectors,with PCM,battery pack customization available.
3. OEM, ODM & Label service.
4. Warranty: 1 year.
5. Good after-sale service.
