P2.5/P3/P4 Water Resistant LED Advertising Screen 2121SMD Black Pearl LED Type

Price Negotiable

Price: Negotiable

MOQ: 1 Piece/Pieces

Delivery Time: Negotiable

Brand: LongRun

Product Description

P2.5/P3/P4 Water Resistant LED Advertising Screen 2121SMD Black Pearl LED Type

Specification

Control system: asynchronous control-- Apache wifi control by laptop or android based cellphone, USB driver updating program, 2~32G SD card in it.

Item		Beauty Series-Indoor ADV Machine
Module specification	Model No.	P2.5	P3	P4
	Pixel pitch(mm)	2.5	3	4
	Pixel density(dots/sqm)	160,000	111,111	62,500
	Pixel configuration	1RGB	1RGB	1RGB
	LED source	SMD2121	SMD2121	SMD2121
	Module size(mm*mm)	160*160	192*192	128*128
	Module resolution(PX*PX)	64*64	64*64	32*32
	Module max power consumption(W)	15	15	10
Main technical parameters	Driving method	constant current	constant current	constant current
	Scan method	1/32	1/32	1/16
	Horizontal viewing angle(Deg)	140	140	140
	Vertical viewing angle(Deg)	140	140	140
	Max brightness(cd/sqm)	1600	1500	1500
	Grey level(bits)	16	16	16
	Refresh rate(Hz)	>3840	>3840	>3840
	Display size(mm*mm)	640*1280	768*1152	768*1280
	Display resolution(PX*PX)	256*512	256*384	192*320
	Cabinet max power consumption(W/pc)	480	360	600
	Cabient average power consumption(W/pc)	160	120	200
	Machine size(mm*mm)	940*1920	940*1920	940*1920
	Machine weight(kg/pc)	90	90	90
	Machine thickness(mm)	80	80	80
	Machine material	die-casting aluminium
	Display color(M)	>16.7
	Input voltage(V)	AC 110V~220V ± 10%
	Serial frequency(Hz)	50~60
	Ingress protection	IP66
	Operation envorionment	Indoor/outdoor
	Working temperature(ºC)	-40º~+65º
	Store humidity(RH)	10%~90%
	Life span(H)	100,000
