High Efficiency Hybrid Solar Power System 30KW -150KW With Lifepo4 Or Lithium Battery

Price Negotiable

Price: Negotiate

MOQ: 1 unit

Delivery Time: 5-8 working days bulk order negotiate

Brand: Fenigal

Product Description

High Efficiency Hybrid Solar Power System Industrial 30KW -150KW With Lifepo4 Or Lithium Battery Good Quality

Items	Configuration
	Model No.	BSM30K-HY	BSM50K-HY	BSM100K-HY	BSM150K-HY	BSM250K-HY	BSM500K-HY
Solar Panel	Quantity	68 units	119 units	238 units	340 units	595 units	1190 units
	Model	BSM455M-72HPH (Mono)
	Max Power	455W			Size	2094103835mm
	Voc	49.8V			Vmp	41.1V
	Isc	11.61A			Imp	11.08A
Hybrid Inverter	Quantity	1 unit	1 unit	1 unit	1 unit	1 unit	1 unit
	Model	BPS30	BPS50	BPS100	BPS150	BPS250	BPS500
	Max PV Power	60/120KW		120/180/240KW		300/360KW	600/660/720KW
	MPPT Operating Voltage	200V-850VDC
	Battery Voltage	150V-850V		420V-850V		500V-850V
	AC Voltage	3P+E, 4wires , 400V
Lithium Battery	Model	BSM-HV series
	Battery Voltage Range	150~850V	420~850V			500~850V
	Battery Bank Capacity (customized)	60KWH	98.4KWH	196.8KWH	295.2KWH	545KWH	1091KWH
	Battery Bank Capacity (90% DOD)	54KWH	88.56KWH	177.12KWH	265.68KWH	490.5KWH	981.9KWH
BOS	Battery Combiner Box	1 set
	Mounting Brackets	1 set
	DC Combiner Box	4 in 1out	7 in 2 out	14 in 2 out	20 in 3 out	14 in 2 out	20 in 3 out
	PV Cable 4mm²	400m	800m	1600m	2200m	1600m	2200m
	DC Breakers	Optional
	MC4 Connectors	20 pairs	26 pairs	50 pairs	70 pairs	50 pairs	70 pairs
