Product Overview
The MPO–6LC Duplex OM4 Fanout Patch Cable is designed for high-density fiber optic interconnections in modern data centers, enterprise networks, and cloud computing environments.
This assembly uses a high-performance MPO (Female/Male) connector on one end and six LC Duplex connectors on the other, providing a reliable breakout solution from trunk cables to equipment ports.
With low-loss OM4 multimode fiber, the cable delivers 40G/100G parallel transmission, excellent optical performance, and stable insertion loss—ideal for high-speed short-reach applications such as TOR/MOR switches, servers, and SAN networks.
Features
High-Density Breakout Design: One MPO connector splits into 6 LC Duplex interfaces, simplifying equipment connections in 40G–10G fanout applications.
Low-Loss Optical Performance: OM4 fiber ensures low attenuation and supports transmission distances up to 150 m at 40G/100G Ethernet.
High-Quality Connector Options: Available in MPO/MTP by US Conec/Japan Nissin (optional), ensuring stable alignment and minimum insertion loss.
Fully Factory-Terminated & Tested: Each assembly undergoes IL/RL testing, 3D interferometer inspection, and end-face cleaning to meet data-center performance requirements.
Plug-and-Play for Fast Deployment: Pre-terminated and polished, ensuring quick installation, reduced labor time, and improved reliability.
Bend-Insensitive Jacket Design: Enhanced durability with LSZH jacket for indoor routing, racks, cabinets, and patch panels.
Specifications
|
Connector A |
1 x MPO (12-Fiber, Male/Female selectable) |
Connector B |
6 x LC Duplex (UPC) |
|
Fiber Mode |
9/125μm Single-Mode |
Cable Diameter |
3.0mm |
|
Fiber Count |
12 |
Wavelength |
850nm /1300nm |
|
Breakout Length |
0.5m |
Cable Diameter |
3 mm round trunk, 2.0 mm tails |
|
Cable Jacket |
LSZH |
Insertion Loss |
MPO≤0.35dB ; LC≤0.2dB |
|
Jacket Color |
Magenta |
Return Loss |
MPO≥60 dB, LC≥50dB |
|
Operate Temperature |
-20~+75°C |
Durability |
≥500 times |
Applications
- 40G to 10G Interconnects: Connect a 40G QSFP+ PSM4 port on a core switch to four 10G SFP+ LR/ER ports on access switches or servers.
- High-Density Backbone: Implement structured cabling between Main Distribution Areas and Equipment Distribution Areas (EDA).
- Direct Equipment-to-Equipment: High-bandwidth direct connections between routers and switches within the same or adjacent racks.
- Telecom Rooms: Suitable for carrier-grade applications requiring long reach and high reliability.
Our Commitment to Quality
Every cable is 100% factory-tested to exceed industry standards before it ships.
- 3D Interferometer Tested: Ensures perfect MPO and LC end-face geometry (radius of curvature, apex offset, etc.).
- End-Face Inspection: Guarantees all optical surfaces are free of scratches and contaminants.
- IL/RL Tested: Every fiber core is individually tested, and a full test report is available.
Need a Different Configuration? We Can Build It.
We offer complete customization services, including:
- Custom lengths
- MPO Gender (Male/Pinned or Female/Unpinned)
- Different Polarities (Type A, B, or C)
- Custom fan-out staggering or lengths
- Other connector types
