LCD Panel 230W 450cd/m² 3x3 Narrow Bezel Video Wall
3x3 videowall lcd video wall with HD video wall controller
| 49-inch LCD splicing screen (1.8mm splice) | ||||||
| Size | 49inch | |||||
| model | VT-AD490LY-W | |||||
| Panel parameters | ||||||
| Panel Type | 49 inch LCD panel | |||||
| Display Size | 1073.78*604 mm(H*V) | |||||
| Display Ratio | 16:9 | |||||
| Backlight Type | LED | |||||
| Resolution | 1920*1080 | |||||
| Display Color | 16.7M(8bit) | |||||
| Brightness | 450cd/m2 | |||||
| Contrast | 3000:1 | |||||
| Viewing Angle | 178° | |||||
| Response Time | ≤6 ms | |||||
| Service Life | 60000 hours | |||||
| Physical Seam | 1.8mm | |||||
| Function | ||||||
| Color Standard | PAL/NTSC/SECAM | |||||
| Menu Language | Simplified chinese, Traditional chinese, English multilingual | |||||
| Operation Method | Controlling software | |||||
| Input/output Interface | ||||||
| D-15 Pin RGB Input (VGA) | 1 | |||||
| DVI Input | 1 | |||||
| hd Input | 1 | |||||
| Composite Video Input (AV) | 1(BNC*1) | |||||
| Composite Video Output (AV) | 1(BNC*1) | |||||
| Control Signal Input | RS232 (rj45-8 interface) | |||||
| Control Signal Loopout | RS232 (rj45-8 interface) | |||||
| Power Supply | ||||||
| Power Input | AC100-240V,50 /60HZ | |||||
| Power Consumption | ≤230W | |||||
| Working Temperature | 0℃—50℃ | |||||
| Storage Temperature | -20℃-60℃ | |||||
| Working/Storage Humidity | 20%-80% | |||||
| Install System | ||||||
| Cabinet/Support | Custom | |||||
| Installation Accessories |
Custom | |||||
| Installation | Cabinet, Wall hanging, Bracket, Building block, Embedded, Mobile, etc |
|||||
| Product Appearance | ||||||
| Product Size | 1020.02*574.61*118.2(mm) | |||||
| Appearance Color | Black | |||||
| Shell Material | Metal | |||||
The picture below shows the rendering photo of the 178-degree full viewing angle of the LCD video wall. The pictures are for reference only.
There are many options for the splicing wall, 1x2, 1x3, 2x2, 2x3, 3x3, 3x4, etc. We will customize the solution according to the customer's requirements. For more details, please contact our customer service, thank you.
FAQ:
1. Q: Are you a factory or trading company ?
A: We are a OEM/ODM factory .
2. Q: What payment methods your company accept ?
A: We accept most ofthe payment methods , but mainly accept T/T ,L/C ,Western Union,Paypal and MoneyGram .
3. Q: How long is the warranty time for your products ?
A: Our officially promised warranty time is one whole year after delivery at best .If a longer warranty period is required to increase the corresponding cost , the warranty period can be up to 3 years .
4. Q: what's the shipment terms and delivery time of your company ?
A: Well, they depends on the quantity of your order . As you know ,we need time to manufacture the machines.but mostly , the shipment time is 3-8 working days after delivery . For Delivery way , for Sample and Bulk order < 100KG , we will kindly suggestExpress and Air freight , when Air freight and Sea shipping for Bulk order >100KG .As for detailed cost , it depends on your final order .
5. Q: Do you give any discount ?
A: I'll surely try my best to help you get those by the best price and good service at the same time .
6. Q: I would like to ask you if it's possible to have my logo on the product .
A: We hope you know that our company VETO perfectly support customized logo service . But we will decide whether to increase the additional cost according to the logo that the customer needs .
