Durable 1 3 5 8 Series Aluminium Sheet Plate Temper H14 H16 H18 O Package
Temper H14, H16, H18, O 1 Series, 3 Series, 5 Series, 8 Series Aluminum Sheet Plates
Our products are widely used in the field of conduction and heat dissipation of a series of products, such as new energy vehicles, lithium batteries, energy storage batteries and son on. We has worked with well-know international companies to develop relevant technical solutions and sample or supply.
Beside increased global performances, an all-aluminum brazed heat exchanger using MPE will also present better corrosion resistance. MPEs are primarily used for the following applications:
Condensers
Evaporators
Oil coolers
Radiators
Heater cores
- Low weight
- Excellent conductor of heat and electricity
- High corrosion resistance
- High recycling value
- High surface quality
- High pressure resistance.
| Mechanical Properties | |||||
| No | Alloy | Temper | Tensile strength |
Yield strength |
Elongation |
| 1 | 1050 | O/F/H111/H112 | ≥ 65 | ≥ 20 | ≥ 25 |
| 2 | 1100 | O/F/H111/H112 | ≥ 75 | ≥ 20 | ≥ 25 |
| 3 | 1197 | O/F/H111/H112 | ≥ 80 | ≥ 25 | ≥ 20 |
| 4 | 3102 | O/F/H111/H112 | ≥ 75 | ≥ 20 | ≥ 25 |
| 5 | 3R03 | O/F/H111/H112 | ≥ 80 | ≥ 25 | ≥ 20 |
| Mechanical property | ||||
| Alloy Code | Temper | Tensile Strength Rm(Mpa) |
Yield Strength (Mpa) |
Elongation(%) |
| TR-010,TR-020,TR-030,TR-040, TR-050,TR-110,TR-310,TR-116, TR-316,TR-111,TR-313,TR-121, TR-131,TR-141,TR-150,TR-151, TR-156Etc. |
O | 95-135* | ≥35* | ≥15* |
| H14 | 140-185 | ≥125 | ≥1.5 | |
| H24 | 140-185 | ≥125 | ≥3 | |
| H16 | 185-225 | 160 | ≥1 | |
| H18 | ≥185 | —— | ≥0.5 | |
| TR-166Etc. Tube material | H24 | 185-235 | ≥150 | ≥8 |
| TR-116,TR-316 Etc.tube material | H14 | 140-185 | ≥125 | ≥3 |
| H24 | 140-185 | ≥125 | ≥8 | |
