RG-59 Cable 24V F970 D28S Battery 100M SDI To HDMI Audio Video Converter
Introduction:
SDI to HDMI Converter Adapter Support RG-59 Cable Transmission Up to 100M
The Mini Converters are incredibly tiny broadcast quality video converters that come in three models, SDI to HDMI Cross Converter, SDI to HDMI Converter , HDMI to SDI Converter. Standard 1/4-20 screw threads for flexible installing. You get HDMI and professional 3G-SDI connections for working with almost SD and HD formats. Flexible double power supply System that supports F970, D28S, E6, battery plate and also power adapter.
Applications :
SDI to HDMI converter excellence compatibility, best image quality and supporting wide signal formats. 3G/HD/SD-SDI to HDMI broadcast grade converter is a professional video format converter which could convert HD digital component serial interface SDI signal to HDMI signal.Widely applied in multimedia broadcast, program production and edit in broadcasting and television, HD video information release, HD video remote transmission, video conference, multimedia advertisement and video security monitoring and so on.
Advanced Features :
1. 1 SDI input, 1 HDMI output, and 1 SDI loop output.
2. Complies with SMPTE 424M, SMPTE 292M, SMPTE 259M.
3. Enhanced HD signal processing technology supports maxim 100 meter 3G-SDI transmission.
4. Supports wide range input voltage from 5V - 24V.
5. Double Power Supply System, with DC adapter or battery.
6. Mini size design easy to carry for engineering.
7. Standard 1/4 screw threads for installing.
8. Power indicator.
9. Heavy duty aluminum housing.
Specifications :
| Model No. | STH2(SDI to HDMI Converter) |
| Input | 3G/HD/SD-SDI x1 |
| Output | 3G/HD/SD-SDI x1 ,HDMI x1 |
| SDI Support Format |
3G-SDI:1080P(60/59.94/50) HD-SDI:1080P(30/29.97/25/24/23.98); 1080I(60/59.94/50); 1080PsF24; 720P(60/59.94/50/30/29.97/25/24); SD-SDI:576I(50),480I(60) |
| HDMI Support Format |
1080P(60/59.94/50/30/29.97/29/25/24); 1080I(60/59.94/50); 1080PsF24; 720P(60/59.94/50/30/29.97/25/24); 576I(50),480I(60) |
| Power Consumption | ≤3W |
| Input Voltage | DC5-24V |
| Connector | DC12V |
| Battery Plate |
F970 (Standard); D28S, E6 (Optional) |
| Install Way | 1/4"-20 Thread Socket |
| Working Temperature | -20°C~60°C |
| Storage Temperature | -30°C~70°C |
| Unit Size | 98.8L×67.4H×22.8D mm |
| Unit Weight | 180g/210g (With F970 Plate) |
