Multi Channel Sesame Corn Color Sorting Machine For Wheat Grain Beans
Multi Channel Sesame Corn Color Sorting Machine For Wheat Grain Beans
Quick Detail:
| Model | Output(T/H) | Carryover | Accuracy | Voltage | Power | Weight | Dimension(mm) |
| GS7 | 3.5-21 | >10:1 | >99.99% | 220V/50HZ | 1.1-1.9KW | 1350kg | 2814*1707*1828 |
Description:
1. Multi-core parallel processing system
Color selection, shape selection, smart selection scheme flexible matching synchronous operation
2.High-quiet image acquisition system
1.9Billion-pixel HD image, micron-level recognition accuracy, nonlinear distortion auto-correction fidelity
3.visual interface
Color selection effect try to show, adjust parameters more intuitive
4. Large output production
Ultra-wide channel, increased single-channel yield by more than 25%
5. One-click intelligence
Good or bad identification, one-click intelligent operation
6. Cloud Connect System
Internet + technology, mobile app smart color selection butler, remote control, real-time online analysis, diagnostic functions
7. Big Data
Massive database, extensive sesame material solutions, one-machine multi-select.
8. Intelligent magnetically controlled high-frequency solenoid valve
National patent, high frequency low consumption, wear-resistant lifetime matching use
Applications:
Sorting effect
The machine can separate the raw material to qualified and reject.
Sorting material
Remove moldy grains and bunt grains in raw corn material in one time, thus to comprehensively improve the quality and fineness of corn.
Equipment feature
- Big data processing
- Cloud Interconnection System
- Visual intelligent image acquisition system
- A intelligence key to operate system
- Intelligent air curtain dedusting system
- Intelligent magnetic control high frequency ejector
- Autonomic computing and super brain intelligent identification
- Light intelligent control dimming system
Specifications:
| Model | Output(T/H) | Carryover | Power(KW) | Voltage | Weight(kg) | Dimension(mm) |
| GS1 | 0.5-3 | >10:1 | 0.3-0.5 | 220V/50HZ | 240 | 975*1550*1400 |
| GS2 | 1-6 | >10:1 | 0.4-0.65 | 220V/50HZ | 500 | 1240*1705*1828 |
| GS3 | 1.5-9 | >10:1 | 0.7-1.1 | 220V/50HZ | 800 | 1555*1707*1828 |
| GS4 | 2-12 | >10:1 | 0.7-1.1 | 220V/50HZ | 1000 | 1869*1707*1828 |
| GS5 | 2.5-15 | >10:1 | 0.7-1.1 | 220V/50HZ | 1100 | 2184*1707*1828 |
| GS6 | 3-18 | >10:1 | 1.1-1.9 | 220V/50HZ | 1350 | 2500*1707*1828 |
| GS7 | 3.5-21 | >10:1 | 1.1-1.9 | 220V/50HZ | 1350 | 2814*1707*1828 |
| GS8 | 2.5-15 | >10:1 | 1.3-2.2 | 220V/50HZ | 1500 | 3129*1707*1828 |
| GS10 | 5-30 | >10:1 | 1.4-2.3 | 220V/50HZ | 1750 | 3759*1710*1828 |
| GS12 | 4-25 | >10:1 | 1.4-2.3 | 220V/50HZ | 1900 | 4389*1710*1828 |
