High Definition Peanut Color Sorter Machine , Optical Sorting Machine
High Definition Peanut Color Sorter Machine , Optical Sorting Machine
Quick Detail:
| Model | Output(T/H) | Carryover | Accuracy | Voltage | Power | Weight | Dimension(mm) |
| N5 | 2.5-15 | >10:1 | >99.99% | 220V/50HZ | 0.7-1.1KW | 1100kg | 2184*1707*1828 |
Description:
1. Multi-core parallel processing system
Color selection, shape selection, smart selection scheme flexible matching synchronous operation
2.High-quiet image acquisition system
1.9Billion-pixel HD image, micron-level recognition accuracy, nonlinear distortion auto-correction fidelity
3.visual interface
Color selection effect try to show, adjust parameters more intuitive
4. Large output production
Ultra-wide channel, increased single-channel yield by more than 25%
5. One-click intelligence
Good or bad identification at a glance, one-click intelligent operation
6. Cloud Connect System
Internet + technology, mobile app smart color selection butler, remote control, real-time online analysis, diagnostic functions
7. Big Data
Massive database, extensive peanut material solutions, one-machine multi-select.
8. Intelligent magnetically controlled high-frequency solenoid valve
National patent, high frequency low consumption, wear-resistant lifetime matching use
Applications:
To sorting variety type of nuts like batan, walnut, almond, pine nut, hazelnut, ginkgo, lotus seed, cashew, chestnut, pistachio, macadamia, peach gum, fig, peony seed, etc.
Specifications:
| Model | Ejectors | Capacity(T/H) | Carryover rate | Accuracy | Voltage | Power(KW) | Weight | Dimension |
| N1 | 64 | 0.5-3 | >10:1 | >99.9% | 220V/50HZ | 0.3-0.5 | 240 | 974*1550*1400 |
| N3 | 192 | 1.5-9 | >10:1 | >99.9% | 220V/50HZ | 0.4-0.65 | 500 | 1554*1707*1828 |
| N4 | 256 | 2-12 | >10:1 | >99.9% | 220V/50HZ | 0.7-1.1 | 800 | 1869*1707*1828 |
| N5 | 320 | 2.5-15 | >10:1 | >99.9% | 220V/50HZ | 0.7-1.1 | 1000 | 2184*1707*1828 |
| N6 | 384 | 3-18 | >10:1 | >99.9% | 220V/50HZ | 1.1-1.9 | 1100 | 2500*1707*1828 |
| N7 | 448 | 3.5-21 | >10:1 | >99.9% | 220V/50HZ | 1.1-1.9 | 1350 | 2814*1707*1840 |
| N8 | 512 | 4-25 | >10:1 | >99.9% | 220V/50HZ | 1.3-2.2 | 1500 | 3129*1710*1828 |
| N10 | 640 | 5-30 | >10:1 | >99.9% | 220V/50HZ | 1.4-2.3 | 1750 | 3759*1710*1828 |
| N12 | 768 | 6-35 | >10:1 | >99.9% | 220V/50HZ | 1.4-2.3 | 1900 | 4389*1710*1828 |
