4cm Mineral Color Sorter
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
15 days
Brand:
Sortdek
Product Description
Low Consumption Powder Ore Sorting Machine , Automatic Quartz Sorting Machine
Parameter
| Model | LKD4 | LKS4 | MP4 | ||||||
| Layer No. | 1 | 2 | 2 | ||||||
| Ejector No. | 320 | 640 | 512 | ||||||
| Throughput(T/H) | 1-4cm | 4-8mesh | 8-16mesh | 1-5cm | 4-8mesh | 8-16mesh | 26-40mesh | 40-70mesh | 70-120mesh |
| 8-12 | 4-8 | 3-6 | 8-12 | 4-8 | 3-6 | 3-5 | 2-4 | 1-2 | |
| Power(KW) | 2.8 | 4.4 | 5 | ||||||
| Air Pressure(Mpa) | 0.6-0.8 | 0.6-0.8 | 0.4-0.6 | ||||||
| Air consumption (㎡/min) | 4 | 5.6 | 2.8 | ||||||
| Weight(kg) | 1650 | 3200 | 2400 | ||||||
| Dimension(mm) | 2977*2883*1734 | 3562*2883*2734 | 2336*2233*2511 | ||||||
Description:
Resorting solution ensure high accuracy and low carryover
High density alloy material chutes reduce abrasion
Dust resistance
Floating design wiper
Highest industrial configuration of 4 nos cameras and 128 nos ejectors equipped with each chute
SMC pneumatic system
Applications:
The raw material could be quartz, Calcium carbonate, feldspar, Cryolite.
