Crawler Mobile Screen Machine With Three Layer Screen Design
Crawler Mobile Stone Screen Machine With Three-Layer Screen Design
Hefei Sortdek Vision Technology Co., LTD., as the integrated solution provider in the field of ore and engineering material treatment, focuses on the R&D and service of material crushing, screening and conveying equipment,relying on the strong production strength of HFM Group, we are committed to providing intelligent one-stop material crushing system solutions.
We choose the crawler mobile crusher as the specialized crushing machine, adding the leveling device, optimizing the electric control system, so that the adaptability of the harsh working environment is further enhanced; adopting inblock casting super rotor, high speed, more stable. The main products are crawler mobile jaw crusher, mobile impact crusher, mobile cone crusher, mobile screen machine and other heavy equipments.
Features & Highlights:
- Using Q355R container grade plate, the amplitude can achieve 7, comparing the same level of screen capacity increases by 30%, excellent screening capacity.
- Plate feeding system can be selected to achieve the screening efficiency of special materials.
- Screen machine three-layer screen design, can screen up to 4 kinds of final products, each finished material conveyor belt can be folded hydraulically, realize the whole machine transport.
- Vibrating screen can achieve hydraulic lifting and descending, easy for maintenance and screen replacement.
- Easy to transport, wireless remote control for moving, can adapt to mountain, wetland and other complex working environment.
Technial Paremeters:
| Feeding Belt | Feeding capacity | 350 t/h | B Belt 2nd Layer | Discharging height | 3100 mm |
| Maximum feeding size | 200 mm | Length×width | 7420×500 mm | ||
| Length×width | 10930×1000 mm | Power | 4 kw | ||
| Feeding height | 2600 mm | C Belt 3rd Layer | Discharging height | 2850 mm | |
| Power | 11 kw | Length×width | 7420×500 mm | ||
| Volumn | 3 m3 | Power | 4 kw | ||
| Vibrating Screen | Length×width | 6500×1800 mm | D Belt Bottom Layer | Discharging height | 3260 mm |
| Power | 17 kw | Length×width | 6580×1000 mm | ||
| Screen Layers | 3 | Power | 7.5 kw | ||
| A Belt 1st Layer | Discharging height | 2800 mm | Whole Machine | Engine power | 85 kw |
| Length×width | 5850×500 mm | Whole machine weight | 32.5 t | ||
| Power | 4 kw | Processing capacity | 120-300 t/h | ||
| Transportation size | 14000×3500×3700mm | ||||
| Working size | 13200×13300×5700mm | ||||
| Screen power | 47.5 kw |
