Construction Scaffolding Joint Coupler Sleeve Coupler

Scaffolding coupler/scaffolding tube end to end joiner clamp, Sleeve coupler, External sleeve coupler. Sleeve Clamp, Scaffolding Joint Box. Scaffolding Sleeve Joiner, used to joint two scaffolding tubes externally one to one, is widely used in the construction of construction projects. In addition to scaffolding, it can also be used for erecting derricks, loading platforms and trestles.

Advantages:

1. Beautiful and practical Plating surface

2. Using punching process, increase safety assurance

3. Screw cap to prevent lose nuts
4. 8.8 class high strength bolt

Construction Scaffolding Joint Coupler Sleeve Coupler

Products	Swivel coupler	Fixed coupler	Fixed girder coupler	Putlog coupler	Scaffolding sleeve coupler	Board Retaining couple
Material	Q235 Carbon Steel	Q235 Carbon Steel	Q235 Carbon Steel	Q235 Carbon Steel	Q235 Carbon Steel	Q235 Carbon Steel
Size	48.3mm	48.3mm	48.3*48.3MM	48.3*48.3MM	48.3*48.3MM	48.3*48.3MM
Weight	1.05kg	1.05kg	1.5kg	0.62kg	0.98kg	0.6kg
Surface treatment	Electric galvanized	Electric galvanized	Electric galvanized,silver color	Electric galvanized,silver color	Electric galvanized,silver color	Electric galvanized,silver color
Craft	pressed	pressed	pressed	pressed	pressed	pressed
Application	construction scaffold	construction scaffold	connect the scaffolding tube	connect the scaffolding tube	connect the scaffolding tube	connect the scaffolding tube



Advantages of Scaffoldingpipe clamp, Scaffolding Tube Coupler
1. Coupler for scaffolding steel tube 48.3mm.
2. Drop forged steel with good breaking strength.
3. Rough surface offers high skip-resistance.
4. T bolt and nut locking, quick to assemble and disassemble.
5. Zinc coated protect coupler clamp from corrosion for a long time.
6. Scaffolding pipe clamps has been tested according to BS1139.
7. Scaffolding tube couplers can connect steel pipes at any direction to form temporary structure.



Package:

Related construction prodcuts we supply:

We also supply formwork accessoris, tie nut, tie rod, plastic sleeve, cone, formwork plate, water stopper, scaffold props, scaffold frame, scaffold coupler, jack base, plastic rebar caps, plastic roman pillar, plastic safety fence, OEM service. Please feel free to contact us for one stop shopping of construction products from China, best price and service will be offered!!!
