Al2o3 Ceramic Kiln Roller High Bending Resistance Prevent Any Pollution
HR970 Super High-Temperature Alumina Ceramic Roller for Kiln, 1100°C, thermal shock resistance, porcelain tile
HR 970 is a high-grade cooling roller with excellent characteristics of lower thermal expansion coefficient, high bending resistance, and long service life.
Applicable field: fast cooling zone of roller kiln, cooling zone.
We adopt Germany prescription with imported materials, will vacuum refining 3 times to make uniform and plasticity mud, air dry three times until qualified for moisture inspection. We pick top-grade body using slurry extrusion molding method, hanging sintering in the kiln which is 1600℃ more than 30 hours. We strictly control every production detail, prevent any pollution in the production line, and using CNC machining to improve accuracy.
We are committed to providing high-quality alumina ceramic roller which is with high-temperature strength, great thermal shock resistance, and the lowest straightness. Offering long life-service for your kiln, it would be the best choice of polishing glazed tile, rustic tile, large size porcelain tile, thick tiles, and wide-body kiln.
| Physical Properties: | HR970 |
| Al2O3+ZrO2 | 70-75 |
| Water Absorption (%) | 10~15 |
| Apparent Porosity (%) | 20-24 |
| Bulk Density (g/cm3) | 2.20-2.50 |
| Bending Strength (Mpa) | 45-60 |
| Thermal Shock Resistance 1300℃ | Very Good |
| Max. Working Temp. (°C) | 1100℃ |
| Straightness | ≤0.07% |
| Outer diameter deviation(mm) | ≥φ50:-0.5 ~ +0.5 |
| ＜φ50:-0.4 ~ +0.5 | |
| Note: other dimensions available on request | |
| Roundness(Dmax-Dmin)mm | ≥φ50:＜0.5 |
| ＜φ50:＜0.4 | |
| Taper(mm) | ≥φ50:＜0.5 |
| ＜φ50:＜0.4 |
| Diameter (mm) | Length (mm) | Diameter (mm) | Length (mm) |
| Ø65 | 3900-4800MM | Ø35 | 3400-3600MM |
| Ø60 | 3900-4700MM | Ø33.7 | 3100-3300MM |
| Ø55 | 3800-4500MM | Ø32 | 3200MM |
| Ø50 | 3600-4200MM | Ø30 | 3100MM |
| Ø45 | 3300-3900MM | Ø29 | 3000MM |
| Ø42 | 3000-3900MM | Ø27 | 2900MM |
| Ø40 | 3200-3600MM | Ø25 | 2600MM |
| Note: other dimensions available on request | |||
