Wall / Window Mount Indoor Central AC Unit Durable With Enhanced Bearing
Wall / Window Mount Indoor Central AC Unit Durable With Enhanced Bearing
Product feature
1. Small size, small footprint, convenient arrangement.Compact size, good balance and quick installation.Symmetrical structure, bright lines, crisp edges, beautiful appearance.
2.Italian AMS production line is adopted to produce high heat transfer efficiency of turbulent fin steel tube heat exchanger, with high efficiency.
3.Fan has three kinds of speed adjustable, and the use of permanent capacitor motor, so that the fan is the most energy-saving, good effect.
4.High precision bearing motor without lubricating oil and special sound-absorbing insulation material are adopted for smooth operation, low noise and long service life.
Main Feature:
1. Control box with ventilation system
2. Original imported circuit board
3. Black heat sink fins for better heat dissipation
4. Original imported compressor
Parameters
| Power supply | V, Ø, Hz | 220, 1,50 | 220, 1,50 | 220, 1,50 | |
| Capacity | Cooling | kW | 8 | 11.2 | 15.5 |
| Heating | kW | 9.4 | 12.5 | 18 | |
| Power | Cooling | kW | 1.86 | 2.6 | 3.96 |
| Heating | kW | 2.19 | 2.91 | 4.09 | |
| COP | Cooling | W/W | 4.3 | 4.30 | 3.91 |
| Heating | W/W | 4.3 | 4.30 | 4.4 | |
| Air volume | m3/min | 60 | 60 | 110 | |
| Connecting pipe |
Liquid | mm(inch) | 9.52(3/8) | 9.52(3/8) | 9.52(3/8) |
| Gas | mm(inch) | 15.88(5/8) | 15.88(5/8) | 19.05(3/4) | |
| Dimension(WxHxD) | mm | 950×834×330 | 950×834×330 | 950×1380×330 | |
| Weight | kg | 70 | 70 | 94 | |
| Noise | Cooling | dB(A) | 54 | 54 | 52 |
| Heating | dB(A) | 56 | 56 | 54 | |
| Signal Line | No.xmm | 2C × 1.0 ~ 1.5 | 2C × 1.0 ~ 1.5 | 2C x 1.0 ~ 1.5 | |
| Refrigerant | name | R410A | R410A | R410A | |
| quantity | kg | 1.8 | 1.8 | 3 | |
| Max quantity of indoor unit | 6 | 6 | 9 | ||
Details
Our Services
a.) Consultation service before, during and after sales;
b.) Project planning and design service (including air conditioner panel and package design to save time for our customers);
c.) Testing of air conditioner until everything is functional;
d.) Management of air conditioner long distance shipping from seller's factory to the specified place by buyer;
e.) Training of air conditioning maintenance and operating personally;
f.) Provide 7 year complete warranty,free spare parts and life-time maintenance service.
