1700C High Temperature Tube Furnace Oven High Purity Alumina Corundum Tube
High Temperature Tube Furnace Oven High Purity Alumina Corundum Tube
High Temperature Tube Furnace Application: This tube furnace is widely used in enterprises and institutions scientific research and small batch production, as well as colleges and universities involved in scientific research and teaching of ceramics, metallurgy, electronics, glass, chemical, machinery, refractory materials, new material development, special materials, building materials in the field.
Max temperature:
1200℃ (HRE Fe-Cr-Al-Mo wire)
1400℃ (SiC Heater)
1600℃ (MoSi2 Heater)
Technical parameter of 40*400mm atmosphere high temperature tube furnace:
| Product name and model | SP-1700T-44 vacuum tube electric furnace |
| Heating tube size(OD×L) | Dia40x400mm |
| Chamber insulation materials | light weight alumina ceramic fiber plate |
| Maximum temperature | 1700°C working time ( < 3 hours) |
| Working temperature | 400-1100°C (adjustable, for long time ) |
| Temperature control | Intelligent 30 segments programmable and PID auto control |
| Heating rate | 1-15℃/min (adjustable) |
| Temperature accuracy | ±1℃ |
| Thermocouple | B type |
| Heating element | MoSi2 heater |
| Ultimate vacuum | -0.1Mpa |
| Vacuum pump specifications model | 0.5A, pumping rate 0.5L/S, power 120W |
| Furnace shell | Double shell with fan cooling |
| Temperature display mode | Four Figure Liquid Crystal Display |
| Working power | AC 1-phase, 110V-240V, 50Hz/60Hz |
| Spare function | installed computer communication module and RS485 communication interface,to realize the remote control. (If there need spare function, cost will be added |
Other sizes of tube furnace can also be available .Welcome to send email to us if you are interest in our tube furnace .
Why Choose Us?
1. Factory Advantages
Xinyu was founded in 2005. We have nearly 17 years of experience in the design and production of high-temperature experimental equipment, with stable quality and a comprehensive daily output of more than 10 sets.
Independent design and research department, constantly innovate and optimize product structure, reduce customer costs and improve product quality.
2. Product materials
The product is made of international standard high-quality ceramic fiber board and ceramic fiber cotton, and the shell is made of SPCC cold-rolled carbon steel plate.
Furnace Shell Structure: Double-layer carbon steel plate shell, surface sprayed with heat resistant plastic powder coating to
ensure that the outer surface temperature of the furnace is ≤40.C.
3. Quality control
Professionals are responsible for each process to check the quality of raw materials and packaging.
Installation test will be carried out before packaging to ensure that each product is intact.
4. After sales service
7 * 24-hour after-sales service to solve all your concerns.
