64L 1700C Vacuum Atmosphere Furnace Argon Atmosphere Chamber Ceramic Lining
64L Argon Atmosphere Chamber Muffle Furnace Ceramic Lining 1700C High Temperature
Features of atmosphere chamber muffle furnace:
SP series atmosphere box furnace can protect materials from oxidation and decarburization with flowing Nitrogen ,argon and other inert gas .It is an ideal furnace for sintering ,reducting under inert -atmosphere in labs of university ,research institution and industrial company .
1. Double shells with fan cooling .the furnace surface temperature is low
2. 30 segments programmable and PID auto control.it can make furnace more intelligent for people to use .
3. High quality alumina ceramic fibers as the furnace liner .The heat resistance is better .
4. It has multi-function such as metal annealing ,quenching atmosphere,surface cream ,light treatment
The supply of technical information together with furnace:
1. Furnace operation manual
2. The maintenance solution of the common problems .
3. Electrical control schematic drawing
Technical support and after sale service :
1. Prompt technical consulation and support will be offered .
2. Provide consumable parts with favorable price
3. A whole year warranty and lifetime maintenance .
Technical parameter of 400x400x400mm atmosphere chamber muffle furnace :
| Product Name | atmosphere chamber muffle furnace |
| Model | SP-1700BA-64L |
| Max Tempearture | 1700℃(<3 Hours) |
| Working Tempearature | 1600℃(Continuous) |
| Max Vacuum | -0.1MPa |
| Inner chamber Size | 400*400*400mm or customizatable |
| Furnace structure | Double Shells with fan cooling |
| Temperature Controller | 50 Segment programmable and PID auto control |
| Temperature Accuracy | +/-1 °c |
| Heating Elements | MoSi2 rod |
| Heating Rate | 15°c/Minutes(Suggestion<10°c) |
| Thermocouple | k type |
| Rated Power | 24KW |
| Rater Voltage | AC 380V (50/60hz) |
Stanard models of SUPER company 1700C atmosphere chamber muffle furnace :
| Model | Chamber size(W*H*Dmm) | Max. Temperature |
| SP-1700BA-1L | 100x100x100mm(4"x4"x4") | 1700℃ |
| SP-1700BA-3.4L | 150x150x150mm(6"x6"x6") | 1700℃ |
| SP-1700BA-4.5L | 150x150x200mm(6"x6"x8") | 1700℃ |
| SP-1700BA-8L | 200x200x200mm(8"x8"x8") | 1700℃ |
| SP-1700BA-12L | 200x200x300mm(8"x8"x12") | 1700℃ |
| SP-1700BA-19L | 250x250x300mm(10"x10"x12") | 1700℃ |
| SP-1700BA-36L | 300x300x400mm(12"x12"x16") | 1700℃ |
| SP-1700BA-49L | 350x350x400mm(14"x14"x16") | 1700℃ |
| SP-1700BA-64L | 400x400x400mm(16”x16”x16”) | 1700℃ |
| SP-1700BA-125L | 500x500x500mm(20”x20”x20”) | 1700℃ |
Special requirement for this furnace is also available .
Delivery times :
♥ For some normal standard size furnaces and components, we have in stock; So we can send out in 2-3 days;
♥ Other customized sizes the delivery time is from 15 days to 30 days according to different products request.
Warranty: one year for free
Our products are warranted to be free from defects in materials or workmanship for one year fromthe date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer
for parts, provided that the customer shall be responsible for any transportation cost. This warrantydoes not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
Any special requirement, please contact with us by email, we will reply you within 24 hours.
