Industry Cast Iron Ingot Induction Melting Furnace 1.5 Ton Steel Loading Capacity
1.5ton Industry Cast Iron Ingot Producing Metal Melting Furnace Induction Oven
1. Applications of casting smelting furnace : used for melting stainless steel, alloy steel, carbon steel.
2. Features of casting smelting furnace : fast speed of melting, saving energy, less burnt loss, pure molten liquid.
3. The aluminum frame of casting smelting furnace is adopted to small capacity smelting furnace with reasonable structure and small capacity, convenient installation and simple maintenance, low maintenance cost.
4. The induction coils of fast melting furnace are double paralleled winded with prolonged coil to make sure the half capacity of furnace molten liquid can be heated by full load power output which will improve overall efficiency. Cooling system is equipped along with the induction coil prolong the lining life.
5. The inner wall of induction coil of large capacity electric furnace is cast with imported high temperature resistant insulation material to prevent of furnace lining leakage.
Metal melting furnace eight protection :
1. over voltage protection
2. over current protection
3. low voltage protection
4. lack phase protection
5. lack voltage protection
6. water pressure protection
7. water temperature protection
8. water flow protection.
SUPER COMPANY'S Metal melting furnace advantages:
- High melting efficiency, good power saving effect, compact structure and strong overload capacity;
- The temperature around the furnace is low, the smoke dust is less, and the working environment is good;
- The operation process is simple and the smelting operation is reliable;
- Uniform metal composition;
- The melting temperature rises quickly, the furnace temperature is easy to control, and the production efficiency is high;
- The furnace has high utilization rate and convenient variety change
Technical parameter of 1.5ton induction steel melting furnace :
| Product name and model | GW-1.5 Medium Frequency Steel Induction Furnace |
| Highest temperature | 1650°c |
| Temperature accuracy | ±5°c |
| Load capacity | 1.5T |
| Melting rate | 480Kg/hour |
| Medium Frequency power | 1000KW |
| Melting frequency | 500Hz |
| Power consumption | 610KWh/t |
| Induction coil voltage | 2800V |
| Circulation Water flow | 25 tons/hour |
| Power supply | AC,3-phase,208/380/400/415/440/465V,50/60Hz |
| Tilting furnace device | Electric reducer |
| Furnace shell structure | Casting aluminum shell |
Models of SUPER COMPANY Induction Steel Melting Furnace
| Model |
Loading capacity (kg) |
IF power (kw) |
supply voltage (V) |
IF-FRE (Hz) |
Melting Rate (kg/h) |
Power consumption (KWh/kg) |
| GW-0.05 | 50 | 45 | 380/400 | 1000 | 45 | 0.56 |
| GW-0.1 | 100 | 85 | 380/400 | 1000 | 85 | 0.56 |
| GW-0.15 | 150 | 135 | 380/400 | 1000 | 125 | 0.55 |
| GW-0.25 | 250 | 250 | 380/400 | 1000 | 200 | 0.55 |
| GW-0.35 | 350 | 300 | 380/400 | 1000 | 300 | 0.67 |
| GW-0.5 | 500 | 400 | 380/400 | 1000 | 350 | 0.67 |
| GW-0.75 | 750 | 500 | 380/400 | 1000 | 500 | 0.67 |
| GW-1 | 1000 | 800 | 380/400 | 1000 | 800 | 0.67 |
| GW-1.5 | 1500 | 1000 | 660 | 500 | 1200 | 0.61 |
| GW-2 | 2000 | 1250 | 660 | 500 | 1600 | 0.61 |
| GW-3 | 3000 | 1600 | 660 | 500 | 2400 | 0.61 |
| GW-4 | 4000 | 2300 | 660 | 500 | 3200 | 0.6 |
| GW-5 | 5000 | 3000 | 950 | 300 | 4500 | 0.6 |
SUPER COMPANY is able to supply more models of metal melting furnace according to customers' requirement ,welcome to send us your requirement by email .
