1400C Celsius SiC Heating 12L Electric Sintering Furnace Metal Ceramic
1400C Celsius SiC Heating 12L Electric Sintering Furnace
Electric Sintering Furnace Instruction :
This heat treatment furnace is the right choice for every laboratory use. These models are distinguished by their exceptional workmanship, advanced and attractive design and high reliability. The muffle furnace is equipped with folding doors or lifting doors at no additional cost.
1. Purpose: Designed for sintering/baking/annealing/quenching of materials in oxygen environment.Widely used in ceramics, metallurgy, electronics, glass, chemical industry, machinery, refractory materials, new material development, special materials, building materials, universities, research institutes, industrial and mining enterprises for powder roasting, ceramic sintering, high temperature experiment, material treatment, quality testing, etc.
2. Furnace body: it is made of carbon steel through precise machining equipment.
3. Appearance: Adopt high-temperature paint baking process to make the appearance beautiful and generous (it can also be sprayed according to the customer's color requirements).
4. Temperature control: The intelligent electronic control system is composed of temperature controller, trigger module and electric appliances by domestic famous brands, ensuring high control accuracy, long service life and easy operation.
5. Heating element: high quality electric furnace wire heating element, uniform heating, smooth surface, long service life.
Technical Parameter of Electric Sintering Furnace:
| model | SP-1400B-12L electric sintering furnace |
| Standard Working Temperature | 1400.C ( continuous ) |
| Maximum Working Temperature | 1300.C ( < 3 hrs) |
| Inside Chamber Size | 200X200X300mm (Customizable) |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~15.C/ min (suggestion:<10.C) |
| Temperature Accuracy | +/- 1.C |
| Working Voltage | AC 220V Single Phase 60/50 Hz (or according to your requirement) |
| Furnace structure | Double shell with fan cooling |
| Heating Element | resistance wire |
| Thermocouple | B type |
| Max. Power | 6KW |
| Standard package included with the furnace: | |
| Part description | Quantity |
| Thermal couple | 1 pc |
| Door block | 1pc |
| Stainless steel hook | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 set |
Stand Model of SUPER Electric Furnace:
| Model | Max. temp. | Chamber Size | Working voltage &power |
| SP-1400B-1L | 1400℃ | 100x100x100mm(4”x4”x4”) | AC,1-phase,220V,1.3KW |
| SP-1400B-3.4L | 1400℃ | 150x150x150mm(6”x6”x6”) | AC,1-phase,220V,2.5KW |
| SP-1400B-4.5L | 1400℃ | 150x150x200mm(6”x6”x8”) | AC,1-phase,220V.3.8KW |
| SP-1400B-8L | 1400℃ | 200x200x200mm(8”x8”x8”) | AC,1-phase,220V,5.5KW |
| SP-1400B-12L | 1400℃ | 200x200x300mm(8”x8”x12”) | AC,1-phase,220V,7KW |
| SP-1400B-18.8L | 1400℃ | 250x250x300mm(10”x10”x12”) | AC,1-phase,220V,8.5KW |
| SP-1400B-36L | 1400℃ | 300x300x400mm(12”x12”x16”) | AC,3-phase,380V,12KW |
| SP-1400B-49L | 1400℃ | 350x350x400mm(14”x14”x16”) | AC,3-phase,380V,15KW |
| SP-1400B-64L | 1400℃ | 400x400x400mm(16”x16”x16”) | AC,3-phase,380V,18KW |
| SP-1400B-125L | 1400℃ | 500x500x500mm(20”x20”x20”) | AC,3-phase,380V,24KW |
| SP-1400B-216L | 1400℃ | 600x600x600mm(24”x24”x24”) | AC,3-phase,380V,30KW |
Many experiments and procedures taken in the lab requiring extreme heat environment from 400-1900.C. For this purpose, the high temperature muffle furnace steps in as the necessary part of laboratory equipment. SUPER furnace are providing the muffle furnace at a affordable cost including box muffle furnace, crucible furnace, dental furnace, atmosphere furnace, vertical furnace, tube furnace and etc.
Delivery Times :
♥For some normal standard size furnaces and components, we have in stock; So we can send out in 2-3 days;
♥Other customized sizes the delivery time is from 15 days to 30 days according to different products request.
Our Warranty for High Temp Furnace:
Warranty: One year limited warranty with lifetime support, excluding heating element and ceramic tube damaged by user.
Attention: Any damages caused by the use of corrosive and acidic gases, and any damage from wrong operate and use are not under the coverage of One Year Limited Warranty.
