Heat Treatment Industrial Muffle Furnace Box Type LCD Display
Heat Treatment Industrial Muffle Furnace Box Type LCD Display
Industrial Muffle Furnace application:
1. LCD temp. controller.
2. Adopts traditional split type structure.
3. More personalized design, easy to install and operate, energy saving.
Industrial Muffle Furnace technical data :
| Model | SP-1200B fast heating ashing industry muffle furnace |
| Power supply | AC 220V 50/60HZ |
| Furnace chamber | 300*300*400mm(W x H x D Customizable) |
| Rated power | 6KW |
| Furnace chamber | 1200 type alumina polycrystalline fibers furnace chamber, scientific design and with durable, good insulation properties. |
| Heating elements | High quality resistance wire |
| Thermocouple | k-type double platinum rhodium thermocouple |
| Temperature control mode | The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 50 segment heating and cooling program |
| Continuous working temperature | ≤1100℃ |
| Maximum temperature | 1200℃ |
| Max. Heating rate | 20℃/min |
| Recommended heating rate | 15℃/min |
| Temperature control accuracy | ±1℃ |
| Standard accessories | Door brick 1 piece ;Crucible tongs 1 piece |
| Optional accessories | Furnace hobs , a variety of corundum crucible, oven glove,computer control software and paperless recorder, etc. |
Standard model of fast heating industry muffle furnace :
| Model | Max. temp | Chamber Size | Working voltage &power |
| SP-1200B-1L | 1200℃ | 100x100x100mm(4”x4”x4”) | AC,1-phase,220V/1KW |
| SP-1200B-3.4L | 1200℃ | 150x150x150mm(6”x6”x6”) | AC,1-phase,220V,1.6KW |
| SP-1200B-4.5L | 1200℃ | 150x150x200mm(6”x6”x8”) | AC,1-phase,220V.2KW |
| SP-1200B-8L | 1200℃ | 200x200x200mm(8”x8”x8”) | AC,1-phase,220V,4KW |
| SP-1200B-12L | 1200℃ | 200x200x300mm(8”x8”x12”) | AC,1-phase,220V,5KW |
| SP-1200B-18.8L | 1200℃ | 250x250x300mm(10”x10”x12”) | AC,1-phase,220V,6KW |
| SP-1200B-36L | 1200℃ | 300x300x400mm(12”x12”x16”) | AC,1-phase,220V,7.5KW |
| SP-1200B-49L | 1200℃ | 350x350x400mm(14”x14”x16”) | AC,1-phase,220V,9KW |
| SP-1200B-64L | 1200℃ | 400x400x400mm(16”x16”x16”) | AC,3-phase,380V,11KW |
| SP-1200B-125L | 1200℃ | 500x500x500mm(20”x20”x20”) | AC,3-phase,380V,15KW |
| SP-1200B-216L | 1200℃ | 600x600x600mm(24”x24”x24”) | AC,3-phase,380V,18KW |
Other size is available
.
Warranty: One year limited warranty with lifetime support, excluding heating element and ceramic tube damaged by user.
Attention: Any damages caused by the use of corrosive and acidic gases, and any damage from wrong operate and use are not under this coverage
Packing and shipping of electric muffle furnace :
Industry muffle furnaces are covered with polyfoam/sponge before put them into the plywood carton,which not only has good shock absorption, impact resistance and nontoxic, odorless, moisture corrosion etc.
Shipment by sea, by air or by express as per customer's requirement.
