4 Pairs FTP Cat6A Cable , Shielded Bare Copper Conductor Custom Color
4 Paires Shielded Bare Copper Conductor FTP Cat6A Cable
Description:
The twisted pair cable used for digital communications, applied in buildings cabling system between patch panels and the output of communication. also used in Residential cabling system between the patch panel and output of communication ,meet the 100MHz data communication. Comply with color coding standard of ANSI/TIA/EIA-568-B
Construction:
|
Conductor |
Material |
Solid Bare Copper |
|
AWG |
23 |
|
|
Insulation |
Material |
HDPE |
|
Color Code |
Blue & White/Blue Stripe |
|
|
Orange & White/Orange Stripe |
||
|
Green & White/Green Stripe |
||
|
Brown & White/Brown Stripe |
||
|
Central Separator |
|
Yes |
|
Polyester Film |
|
Yes |
|
Drain Wire |
|
Yes |
|
Shield |
Individual Shield & Material |
No |
|
Outer Shield & Material |
Yes(AL Foil) |
|
|
Jacket |
Material |
PVC/LSZH |
|
Color |
||
|
Rip Cord |
Per Customer Request |
|
|
Marking |
Per Customer Request |
Features:
- Conductor: Stranded Copper
- Insulation Material: HDPE
- Shield: Aluminium foil shielded each Pairs
- Jacket: PVC (RoHS compliant)
- Mold Injection parts: Snagless mold boot
- Connector : 50μ'' gold plated 8P8C short body RJ45
- Transfer rate : up to 1000Mbps (Gigabit Ethernet), applicable to 10G Base TX
- Wiring: complies with TIA/EIA 568B standard
- Mating cycles: more than 1000 times (at least)
- Available lengths: 1/2/3/5/7/10/14/25/50 feet(0.3/0.5/1/2/3/5/10/15/20meter)
- Suitable temperature: -10 °C ~ 45 °C
Applications:
- Network Adapters,
- Hubs,
- Switches,
- Routers,
- DSL/Cable Modems,
- Patch Panels
- Other Computer Networking applications.
