Optical Structure 1650nm PLC 1x16 1x32 Fiber Optic Splitter

Price Negotiable

Price: $10.00 - $60.00 / Piece

MOQ: 50 Piece/Pieces

Delivery Time: Negotiable

Brand: Haiyu optical

Product Description

Manufacturer supply 1x2/1x4/1x8/1x16 fiber power splitter

Special Features :

· All-optical Structure

· Hi-reliability

· Low PDL, Low Insertion Loss

· Hi-directivity, High Return Loss

· Good stability and reliability

· Excellent polarization insensitivity

· Flexible packaging

· Operating wavelength: 1,310nm or 1,550nm, and other wavelength is available on requests

· Coupling ratio: 10/90, 20/80, 30/70, 40/60, 50/50, and customized ratios are available

· FC, SC, ST , LC, LC/APC, SC/APC, MU and FC/APC fiber optic connectors are available

Applications :

· Optical LAN & WAN & CATV

· FTTH project & FTTX Deployments

· Broadband High-bit rate data transmission

· Active device terminations

· Testing instruments

· Optical fiber communication networks

· PON Networks

· Optical Signal Distribution

Specifications
1*N	1*4	1*8	1*16	1*32	1*64
Operating wave length (nm)	1260-1650	1260-1650	1260-1650	1260-1650	1260-1650
Insertion loss(dB) Max(S/P):	7.4/7.2	10.7/10.5	13.7/13.5	16.9/16.5	21
Loss homogeneity(dB) Max	0.8	1	1.4	1.9	2.7
Return loss(dB) Min(S/P)	50/55	50/55	50/55	50/55	50/55

Operating temperature: -40 ~ +85
Storage temperature: -40 ~ +85
Splitting ratio: average
Type: 1X32
Fiber cable outer size: 0.9, 2.0, 3.0mm(D) are available
Fiber lead length: 1.5m or customized
Transmission mode: SM G.652 G.655 or MM 50/125,62.5/125
In/Out put way: FC, SC, ST are optional
In/Out put connecter: PC, UPC, APC are optional
