SS304 Metal Tower Packing Pall Ring 25mm 38mm For Adsorption / Scrubbing
SS304 Metal Tower Packing Pall Ring 25mm 38mm For Adsorption / Scrubbing
Product Description of Metal Random Packing
Metal Random Packing / Pall rings packing shows its interior and exterior surface contact which is beneficial to resist plugging, nesting, and fouling
all along in with the distribution of liquid and gas. Pall rings function with versatility, high resistance to fouling, high
temperature, and can be easily soaked.Metal pall ring is an industry standard design media developed from the raschig ring and is used widely in allvariety of applications. By minimizing the number of contours and crevices that can cause liquid hold-up andpotential entrainment, the metal pall ring's geometry enables high gas and liquid transfer rates.
| Product Name | Stainless Steel Metal Pall Ring |
| Material | metal, stainless steel, carbon steel, Aluminum alloy etc. |
| Surface Area | 62 - 346 m2/m3 |
| Bulk Density | 145 - 345 kg/m3 |
| Feature | Corrosion and Heat Resistance |
| Size | 16mm,25mm,38mm,50mm, 76mm,or customized |
| Certification | ISO9001 |
| Place of Origin | Hebei Province,China |
| Brand Name | Yuanhai |
Specifications of Metal Random Packing
| Model | Pall Ring | |||
| Material | Carbon Steel; SS 304, 304L, 410, 316, 316L, etc. | |||
|
Sizes |
Bulk density |
Number |
Surface area |
Free volume |
| 16×16×0.3 | 345 | 201000 | 346 | 95.5 |
| 25×25×0.3 | 214 | 51000 | 212 | 96.2 |
| 38×38×0.4 | 193 | 15000 | 145 | 96.7 |
| 50×50×0.5 | 182 | 6500 | 106 | 97.5 |
| 76×76×0.6 | 142 | 1830 | 69 | 97.4 |
| 89×89×0.7 | 145 | 1160 | 62 | 97.1 |
Advantages of Metal Random Packing
Lower pressure drop
Good liquid/gas distribution and higher mass transfer efficiency versatility,easily wettable, high resistance to fouling ,high
temperature.
High Mechanical strength ,suitble for depper beds
Good liquid/gas distribution and higher mass transfer efficiency versatility
Application of Metal Random Packing
It's available for rectification towers, cokable systems, crude distillation unit, desulphurization system, gas liquid
separator.And it is widely used in petrochemical industry, chemical industry and environmental protection, etc..
Material:carbon steel, stainless steel304 304l 410 316 316l or Aluminum alloy, etc.
Company Profile
1. Is your company a manufacturer or a trading company?
We are a manufacturer located in Anping County, China.
2. Do you have inport-export right?
Yes, we do. Our factory has been certificated as an import-export enterprise.
3. What is your payment mode?
30% in advance and 70% before delivery by T/T, WESTERN UNION, L/C or negotiated.
4. How about your packing?
We usually packed in plastic material inside and then wooden box outside.
5. How long is your delivery?
Usually 10-20 days after order confirmed, according the quantity ordered.
6. Is it sample available?
Yes, small pieces of sample are available in our company.
