Stainless Steel Anticorrosion Metal Random Packing Pall Ring Inner Arc Ring 25*25*0.4mm
Stainless Steel Metal Random / Pall Ring Metal Inner Arc Ring 25*25*0.4mm
Product Description of Metal Random Packing
It is made of materials like carbon steel, stainless steel or Aluminum alloy, etc. The product has features such as thin wall, heat resistant, high free volume, high capacity, low resistance, high separation efficiency and so on.
Carbon steel, stainless steel including 304, 304L, 410,316, 316L
| Product Name | Stainless Steel Metal Pall Ring |
| Material | metal, stainless steel, carbon steel, Aluminum alloy etc. |
| Surface Area | 62 - 346 m2/m3 |
| Bulk Density | 145 - 345 kg/m3 |
| Feature | Corrosion and Heat Resistance |
| Size | 16mm,25mm,38mm,50mm, 76mm,or customized |
| Certification | ISO9001 |
| Place of Origin | Hebei Province,China |
| Brand Name | Yuanhai |
Specifications of Metal Random Packing
|
Size (mm) |
Bulk density (kg/m3) |
Number (per m3) |
Surface area (m2/m3) |
Free volume (%) |
|
16*16*0.3 |
360 |
201000 |
346 |
95.5 |
|
25*25*0.4 |
302 |
51000 |
212 |
96.2 |
|
25*25*0.5 |
400 |
51000 |
216 |
95 |
|
25*25*0.6 |
461 |
51000 |
219 |
94.2 |
|
38*38*0.4 |
218 |
15000 |
143 |
97.2 |
|
38*38*0.5 |
262 |
15180 |
145 |
96.7 |
|
38*38*0.6 |
328 |
15000 |
146 |
95.9 |
|
50*50*0.5 |
194 |
6500 |
106 |
97.5 |
|
50*50*0.7 |
285 |
6500 |
108 |
96.4 |
|
50*50*0.9 |
365 |
6500 |
109 |
95.4 |
|
76*76*0.8 |
205 |
1830 |
69 |
97.4 |
|
90*90*1.0 |
229 |
1160 |
62 |
97.1 |
The above data is reference to material stainless steel (AISI304) in the material thickness shown. Other wall thicknesses are available on request.
Material available: carbon steel, stainless steel including 304, 304L, 410,316, 316L.
Features of Metal Random Packing
- Popular random packing.
- High flux.
- High efficiency.
- High load elasticity.
- Excellent stain resistance.
- Low pressure drop.
Package
- Covered with moisture-proof paper.
- Packed in dry boxes which have enough strength to withstand impact.
Application of Metal Random Packing
- Metal pall rings are widely used in kinds of separation, absorption, desorption and pressure reducing devices.
- Metal pall rings are commonly applied to all sorts of decarbonization and system of synthetic ammonia.
